Home Fotoelektrik Sensörler GSE2FS-E1161 – 1121030 🔍 GSE2FS-E1161 – 1121030 ✉ Teklif Al Teklif Al Stok kodu: 1121030 Kategoriler: Fotoelektrik Sensörler Marka: SICK Açıklama Tecnichal data Features Functional principle Through-beam photoelectric sensor Dimensions (W x H x D) 4.5 mm x 21 mm x 11 mm Housing design (light emission) Rectangular Minimum detectable object (MDO) 1.8 mm Sensing range max. 0 mm … 1,300 mm Sensing range 0 mm … 1,000 mm Type of light Visible red light Light source PinPoint LED Light spot size (distance) Ø 100 mm (1,000 mm) Wave length 660 nm Adjustment None Mechanics/electronics Supply voltage UB 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption 20 mA Switching output NPN Switching mode Dark switching Output current Imax. ≤ 50 mA Response time < 0.625 ms Switching frequency 800 Hz Connection type Cable, 3-wire, 2 m Cable material PVC Cable diameter Ø 2.3 mm Circuit protection A C D Weight 39.8 g Housing material Plastic, VISTAL® Optics material Plastic, MABS Enclosure rating IP67 Ambient operating temperature –20 °C … +50 °C Ambient temperature, storage –40 °C … +70 °C UL File No. NRKH.E348498 & NRKH7.E348498 Repeatability (Ta not constant) 0.1 mm Classifications ECLASS 5.0 27270901 ECLASS 5.1.4 27270901 ECLASS 6.0 27270901 ECLASS 6.2 27270901 ECLASS 7.0 27270901 ECLASS 8.0 27270901 ECLASS 8.1 27270901 ECLASS 9.0 27270901 ECLASS 10.0 27270901 ECLASS 11.0 27270901 ECLASS 12.0 27270901 ETIM 5.0 EC002716 ETIM 6.0 EC002716 ETIM 7.0 EC002716 ETIM 8.0 EC002716 UNSPSC 16.0901 39121528 İlgili ürünler Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, NPN Output, 50 mm Gap, Plastic, 4 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LNA2-P4ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git Endüstriyel bağlantı kablosu – 42CA-U2MNA-A2ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git 18 mm Cylindrical Sensor, 18 mm Cylindrical, Transmitted Beam Receiver, Infrared, Manually Adjustable, PNP, DC Complementary LO/DO, 4 Pin Micro Quick Disconnect, Plastic, 18mm Mount, 1.00 ms, 3 mm Minimum Sensing Distance, 16000 mm Operating Distance, 160 – 42CA-R1MPA1-D4ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, NPN Output, 120 mm Gap, Plastic, 3 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LNA4-P3ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git
Tecnichal data Features Functional principle Through-beam photoelectric sensor Dimensions (W x H x D) 4.5 mm x 21 mm x 11 mm Housing design (light emission) Rectangular Minimum detectable object (MDO) 1.8 mm Sensing range max. 0 mm … 1,300 mm Sensing range 0 mm … 1,000 mm Type of light Visible red light Light source PinPoint LED Light spot size (distance) Ø 100 mm (1,000 mm) Wave length 660 nm Adjustment None Mechanics/electronics Supply voltage UB 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption 20 mA Switching output NPN Switching mode Dark switching Output current Imax. ≤ 50 mA Response time < 0.625 ms Switching frequency 800 Hz Connection type Cable, 3-wire, 2 m Cable material PVC Cable diameter Ø 2.3 mm Circuit protection A C D Weight 39.8 g Housing material Plastic, VISTAL® Optics material Plastic, MABS Enclosure rating IP67 Ambient operating temperature –20 °C … +50 °C Ambient temperature, storage –40 °C … +70 °C UL File No. NRKH.E348498 & NRKH7.E348498 Repeatability (Ta not constant) 0.1 mm Classifications ECLASS 5.0 27270901 ECLASS 5.1.4 27270901 ECLASS 6.0 27270901 ECLASS 6.2 27270901 ECLASS 7.0 27270901 ECLASS 8.0 27270901 ECLASS 8.1 27270901 ECLASS 9.0 27270901 ECLASS 10.0 27270901 ECLASS 11.0 27270901 ECLASS 12.0 27270901 ETIM 5.0 EC002716 ETIM 6.0 EC002716 ETIM 7.0 EC002716 ETIM 8.0 EC002716 UNSPSC 16.0901 39121528
