Tecnichal data
| Nominal value output voltage 1 | 24 V |
| Secondary voltage adjustable | No |
| Nominal value output current 1 | 20 A |
| Power output | 480 W |
| Voltage type of supply voltage | AC/DC |
| Rated supply voltage at AC 50 Hz | 100 V |
| Rated supply voltage at AC 60 Hz | 100 V |
| Rated supply voltage at DC | 110 V |
| Power reserves | 20 % |
| DC OK relay contact | Yes |
| Hot-swap | Yes |
| Input inrush current limiter | Active |
| Power factor | 0.95 typical |
| External input fuse, min | B-10 A or C-10 A |
| Power losses | 24.2 W typical |
| Derating | 12 W/ðC |
| Efficiency | 95.2 % typical |
| Input inrush current | 10 A/4.5 A |
| Output voltage stabilized | Yes |
| Rail mounting possible | Yes |
| Stabilized | Yes |
| Adjustment range | Fixed |
| Height | 124 mm |
| Depth | 127 mm |
| Direct mounting possible | No |
| Width | 48 mm |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Plug-in connection |
| MTBF | 543 kh (+40 ðC, SN29500) |
| Wall mounting possible | Yes |
| Ripple and noise, max | 50 mV |
| Operating temperature | -40 ðC |
| Lifetime, min | 90 kh (+40 ðC) |
| Weight | 850 g |
