| certificates / approvals |  |
 |
suitable for safety functions |
yes |
|---|---|
housing material |
plastic |
switching distance |
8 mm |
number of protected contact energized outputs |
2 |
type of electric connection |
cable |
cable length |
10 m |
protected switch distance ON |
8 mm |
protected switch distance OFF |
18 mm |
cross-/short circuit identification possible |
yes |
degree of protection (IP) |
IP67 |
type of actuation |
transponder |
category (ISO 13849-1) |
4 |
|---|---|
PL (ISO 13849-1) |
Level e |
SILCL (IEC 62061) |
3 |
PFHd (High demand mode) |
2.24 E-9 1/h |
HFT |
1 |
TM |
20 a |
max. output current at protected output |
400 mA |
|---|
number of protected semiconductor outputs |
2 |
|---|
width sensor |
36 mm |
|---|---|
height of sensor |
26 mm |
length of sensor |
13 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27270105 |
ETIM 9.0 |
EC001829 |
ETIM 8.0 |
EC001829 |
ETIM 7.0 |
EC002544 |
ETIM 6.0 |
EC002544 |
ETIM 5.0 |
EC002544 |
ETIM 4.0 |
EC002544 |
ROHS conformity status |
compliant |
|---|---|
REACH-SVHC conformity status |
compliant |
