| certificates / approvals |  |
 |
connection type |
screw connection |
|---|---|
plug-in socket |
no |
remote operation possible |
no |
only for remote control |
no |
function flashing, starting with pause, fixed time |
no |
function flashing, starting with pulse, fixed time |
no |
clock function, starting with pause, variable |
no |
clock function, starting with pulse, variable |
no |
number of relay outputs, undelayed, change-over contacts |
0 |
number of relay outputs, delayed/undelayed selectable |
no |
number of relay outputs, undelayed, normally closed |
0 |
number of relay outputs, undelayed, normally open |
0 |
number of relay outputs, delayed, change-over contacts |
0 |
number of relay outputs, delayed, normally open |
0 |
number of relay outputs, delayed, change-over contacts |
1 |
semiconductor output |
no |
function delay-on energization |
no |
function floating contact on energization |
no |
function star-delta |
no |
function delay on de-energization |
yes |
function floating contact on de-energization |
no |
function pulse shaping |
no |
type of excitation |
AC |
|---|---|
with auxiliary voltage |
no |
min. rated AC voltage for controls, 50 Hz |
170 V |
max. rated AC voltage for controls, 50 Hz |
264 V |
min. rated AC voltage for controls, 60 Hz |
170 V |
max. rated AC voltage for controls, 60 Hz |
264 V |
min. rated frequency |
50 Hz |
max. rated frequency |
60 Hz |
min. adjustable time |
0.1 sec |
max. adjustable time |
120 sec |
depth |
79 mm |
|---|---|
width |
22.5 mm |
height |
100 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27371605 |
ETIM 9.0 |
EC001439 |
ETIM 8.0 |
EC001439 |
ETIM 7.0 |
EC001439 |
ETIM 6.0 |
EC001439 |
ETIM 5.0 |
EC001439 |
ROHS conformity status |
compliant/exempted |
|---|---|
ROHS exceptions |
III-6(c) |
REACH-SVHC conformity status |
Duty-To-Declare |
REACH-SVHC substances |
Lead |
REACH-SVHC CAS numbers |
7439-92-1 |
