Tecnichal data
| Width | 12 mm |
| Height | 51.5 mm |
| Density | 25 pcs/ft (83 pcs/m) per UL/CSA/IEC/ATEX |
| Colour | White |
| Length | 80.5 mm |
| Wire strip length | 18 mm per UL/CSA/IEC/ATEX |
| Wire range | 18…6 AWG rated cross section per UL/CSA, 16 mmò rated cross section per IEC, 16 mmò rated cross section per ATEX |
| Current, max | 62 A per UL/CSA, 76 A per IEC, 64 A per ATEX |
| Voltage rating | 600V AC/DC per UL/CSA, 1000V AC/DC per IEC, 550V AC/DC per ATEX |
| Type of electrical connection 1 | Push-in clamp connection |
| Operating temperature | -60 ðC |
