Home Konnektörler SYSTEM PLUG SP2, M12-8 W.EXTENSION – 2093100 🔍 SYSTEM PLUG SP2, M12-8 W.EXTENSION – 2093100 ✉ Teklif Al Teklif Al Stok kodu: 2093100 Kategoriler: Konnektörler Marka: SICK Açıklama Tecnichal data Features System part System plug Function range SP2 Items supplied System plug Functions Protective operation ✔ Automatic calibration of the protective field width ✔ Restart interlock ✔ External device monitoring (EDM) ✔ Cascading ✔ Smart presence detection ✔ Reduced resolution ✔ Dynamic protective field width during operation ✔ Sender with reduced scanning range ✔ Differentiation between person and material 2-signal muting ✔ Smart Box Detection ✔ Interfaces System connection Male connector M12, 8-pin PIN assignment See table in “Pin assignment” graphic Length of cable 200 mm Cable diameter 5 mm Extension connection Female connector M12, 5-pin Length of cable 150 mm Cable diameter 5 mm Configuration method DIP switch Application diagnostic output (ADO) ✔ IO-Link ✔ Electrical data Protection class III (IEC 61140) Supply voltage VS 24 V DC (19.2 V … 28.8 V) Ripple ≤ 10 % Ambient data Ambient operating temperature –30 °C … +55 °C Storage temperature –30 °C … +70 °C Air humidity 15 % … 95 %, Non-condensing Vibration resistance 5 g, 10 Hz … 55 Hz (IEC 60068-2-6) Shock resistance 10 g, 16 ms (IEC 60068-2-27) Classifications ECLASS 5.0 27272704 ECLASS 5.1.4 27272704 ECLASS 6.0 27272704 ECLASS 6.2 27272704 ECLASS 7.0 27272704 ECLASS 8.0 27272704 ECLASS 8.1 27272704 ECLASS 9.0 27272704 ECLASS 10.0 27272704 ECLASS 11.0 27272704 ECLASS 12.0 27272704 ETIM 5.0 EC002549 ETIM 6.0 EC002549 ETIM 7.0 EC002549 ETIM 8.0 EC002549 UNSPSC 16.0901 46171620 İlgili ürünler Ethernet Modülleri 4 Port GbE ITA-EM Module with RJ45 connector – ITA-EM-NC22-C0A1EAdvantechKonnektörler ₺450,00 Ürüne Git MCS Mounting System Control Plug – 141A-APC8ALLEN BRADLEYKonnektörler ₺450,00 Ürüne Git Ethernet Modülleri 4 Port GbE ITAM Module with RJ45 connector – ITAM-NC02-C0A1EAdvantechKonnektörler ₺450,00 Ürüne Git Plug-In Control Plug – 141A-APC12ALLEN BRADLEYKonnektörler ₺450,00 Ürüne Git
Tecnichal data Features System part System plug Function range SP2 Items supplied System plug Functions Protective operation ✔ Automatic calibration of the protective field width ✔ Restart interlock ✔ External device monitoring (EDM) ✔ Cascading ✔ Smart presence detection ✔ Reduced resolution ✔ Dynamic protective field width during operation ✔ Sender with reduced scanning range ✔ Differentiation between person and material 2-signal muting ✔ Smart Box Detection ✔ Interfaces System connection Male connector M12, 8-pin PIN assignment See table in “Pin assignment” graphic Length of cable 200 mm Cable diameter 5 mm Extension connection Female connector M12, 5-pin Length of cable 150 mm Cable diameter 5 mm Configuration method DIP switch Application diagnostic output (ADO) ✔ IO-Link ✔ Electrical data Protection class III (IEC 61140) Supply voltage VS 24 V DC (19.2 V … 28.8 V) Ripple ≤ 10 % Ambient data Ambient operating temperature –30 °C … +55 °C Storage temperature –30 °C … +70 °C Air humidity 15 % … 95 %, Non-condensing Vibration resistance 5 g, 10 Hz … 55 Hz (IEC 60068-2-6) Shock resistance 10 g, 16 ms (IEC 60068-2-27) Classifications ECLASS 5.0 27272704 ECLASS 5.1.4 27272704 ECLASS 6.0 27272704 ECLASS 6.2 27272704 ECLASS 7.0 27272704 ECLASS 8.0 27272704 ECLASS 8.1 27272704 ECLASS 9.0 27272704 ECLASS 10.0 27272704 ECLASS 11.0 27272704 ECLASS 12.0 27272704 ETIM 5.0 EC002549 ETIM 6.0 EC002549 ETIM 7.0 EC002549 ETIM 8.0 EC002549 UNSPSC 16.0901 46171620
