| certificates / approvals |  |
 |
connection type |
push-In connection//true |
|---|---|
number of phases |
3 phase power supply |
suitable for modular version |
no |
mounting type, other |
no |
mounting type, wall mounting |
no |
rail mounting possible |
yes |
housing material |
metal |
operating temperature min. |
-25 °C |
operating temperature max. |
70 °C |
relative humidity min. |
0 % |
relative humidity max. |
95 % |
storage temperature / transport min. |
85 °C |
storage temperature / transport max. |
-40 °C |
degree of protection (IP) |
IP20 |
pollution degree |
2 |
display |
LED |
|---|---|
short-circuit protective device |
current limiting (hiccup mode) |
cooling |
free convection |
control “Adj” |
trimming potentiometer for fine-tuning of U(out) |
type of output voltage |
DC |
|---|---|
power output |
960 W |
output voltage stabilized |
yes |
output voltage |
48 V |
min. output voltage |
22.5 V |
max. output voltage |
28.5 V |
min. output voltage |
45 V |
max. output voltage |
56 V |
Over voltage proctection (OVP) |
≤ 59.2 V |
output current |
20 A |
type of voltage (input voltage) |
|
|---|---|
input voltage DC min. |
530 V |
input voltage DC max. |
675 V |
primary voltage range |
400 V |
min. input voltage |
400 V |
max. input voltage |
500 V |
input voltage AC min. |
350 V |
input voltage AC max. |
575 V |
rated frequency min. |
47 Hz |
rated frequency max. |
63 Hz |
input current, max. |
2.2 A |
max. starting current |
17 A |
input fuse |
– |
depth |
171.9 mm |
|---|---|
width |
100 mm |
height |
129 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27049002 |
ETIM 9.0 |
EC002540 |
ETIM 8.0 |
EC002540 |
ETIM 7.0 |
EC002540 |
ETIM 6.0 |
EC002540 |
ETIM 5.0 |
EC002540 |
