connection type |
plug-in connection |
|---|---|
bus connection included |
yes |
bus system EIB/KNX |
yes |
color |
grey |
mounting method |
surface mounted (plaster) |
RAL-number (akin) |
7035 |
degree of protection (IP) |
IP20 |
type of current |
AC |
|---|---|
manual control/hand actuation |
yes |
max. number of venetian-blind outputs |
2 |
voltage of shutter output |
230 V |
voltage type of shutter output |
AC |
current of shutter output |
8 A |
operating voltage |
230 V |
|---|---|
bus input |
KNX TP1 |
voltage type |
AC |
different phases connectable |
no |
halogen free |
yes |
|---|---|
material |
plastic |
height |
112 mm |
|---|---|
width |
254 mm |
depth |
32 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27143128 |
ETIM 9.0 |
EC001330 |
ETIM 8.0 |
EC001330 |
ETIM 7.0 |
EC001330 |
ETIM 6.0 |
EC001330 |
ETIM 5.0 |
EC001330 |
ETIM 4.0 |
EC001330 |
ETIM 3.0 |
EC001330 |
ROHS conformity status |
compliant/exempted |
|---|---|
ROHS exceptions |
III-6(c) |
REACH-SVHC conformity status |
Duty-To-Declare |
REACH-SVHC substances |
Lead |
REACH-SVHC CAS numbers |
7439-92-1 |
