| certificates / approvals |
connection type |
screw connection |
|---|---|
number of change-over contacts |
2 |
detachable clamps |
no |
drive, polarization |
polarity free |
drive, function |
mono stable |
forced-guided contacts |
no |
complete with socket |
yes |
degree of protection (IP) |
IP20 |
type of excitation |
AC |
|---|---|
rated frequency, auxiliary-/control circuit |
50 – 60 |
min. rated frequency, auxiliary/control current circuit |
50 Hz |
max. rated frequency, auxiliary/control current circuit |
60 Hz |
min. nominal voltage DC |
230 V |
lower nominal voltage DC |
184 V |
upper nominal voltage DC |
253 V |
depth |
76 mm |
|---|---|
width |
15.8 mm |
height |
78.6 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27371601 |
ETIM 9.0 |
EC001437 |
ETIM 8.0 |
EC001437 |
ETIM 7.0 |
EC001437 |
ETIM 6.0 |
EC001437 |
ETIM 5.0 |
EC001437 |
ETIM 4.0 |
EC001437 |
ROHS conformity status |
compliant |
|---|---|
REACH-SVHC conformity status |
compliant |
