Home Fotoelektrik Sensörler RAY10-KZ3EBLP06 – 1098291 🔍 RAY10-KZ3EBLP06 – 1098291 ✉ Teklif Al Teklif Al Stok kodu: 1098291 Kategoriler: Fotoelektrik Sensörler Marka: SICK Açıklama Tecnichal data Features Functional principle Photoelectric retro-reflective sensor Functional principle detail Dual lens, Reflex Array Dimensions (W x H x D) 21.5 mm x 36 mm x 37.7 mm Housing design (light emission) Rectangular Minimum object size 5 mm, position-independent detection within the light array Detection height 25 mm Sensing range max. 0 m … 1.5 m Distance of the sensor to reflector 0.3 m … 1.5 m Type of light Visible red light Light source PinPoint LED Light spot size (distance) 37 mm x 12 mm (1 m) Wave length 635 nm Adjustment Potentiometer Special applications Detecting transparent objects, Detecting perforated objects, Detecting uneven, shiny objects, Detecting objects with position tolerances, Detecting flat objects Mechanics/electronics Supply voltage UB 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption 30 mA Switching output PNP Switching mode Dark switching Signal voltage PNP HIGH/LOW Approx. VS – 2.5 V / 0 V Signal voltage NPN HIGH/LOW Approx. VS / < 2.5 V Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Connection type Cable with M8 male connector, 4-pin, 1,000 mm Cable material PVC Conductor cross section 0.13 mm² Cable diameter Ø 3.6 mm Circuit protection A B C D 10) Protection class III Weight 130 g Housing material Plastic, ABS Optics material Plastic, PMMA Enclosure rating IP67 Items supplied RAY10 on bracket #4101235 with P250F on bracket #4101760 Ambient operating temperature –40 °C … +60 °C 11) Ambient temperature, storage –40 °C … +70 °C UL File No. NRKH.E189383 & NRKH7.E189383 Classifications ECLASS 5.0 27270902 ECLASS 5.1.4 27270902 ECLASS 6.0 27270902 ECLASS 6.2 27270902 ECLASS 7.0 27270902 ECLASS 8.0 27270902 ECLASS 8.1 27270902 ECLASS 9.0 27270902 ECLASS 10.0 27270902 ECLASS 11.0 27270902 ECLASS 12.0 27270902 ETIM 5.0 EC002717 ETIM 6.0 EC002717 ETIM 7.0 EC002717 ETIM 8.0 EC002717 UNSPSC 16.0901 39121528 İlgili ürünler Distance Measurement Sensor – 45DMS-B8LAT1-D4ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, PNP Output, 120 mm Gap, Plastic, 4 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LPA4-P4ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, NPN Output, 120 mm Gap, Plastic, 4 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LNA4-P4ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git Photoelectric Accessories, Mounting, Kit – 129-135ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git
Tecnichal data Features Functional principle Photoelectric retro-reflective sensor Functional principle detail Dual lens, Reflex Array Dimensions (W x H x D) 21.5 mm x 36 mm x 37.7 mm Housing design (light emission) Rectangular Minimum object size 5 mm, position-independent detection within the light array Detection height 25 mm Sensing range max. 0 m … 1.5 m Distance of the sensor to reflector 0.3 m … 1.5 m Type of light Visible red light Light source PinPoint LED Light spot size (distance) 37 mm x 12 mm (1 m) Wave length 635 nm Adjustment Potentiometer Special applications Detecting transparent objects, Detecting perforated objects, Detecting uneven, shiny objects, Detecting objects with position tolerances, Detecting flat objects Mechanics/electronics Supply voltage UB 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption 30 mA Switching output PNP Switching mode Dark switching Signal voltage PNP HIGH/LOW Approx. VS – 2.5 V / 0 V Signal voltage NPN HIGH/LOW Approx. VS / < 2.5 V Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Connection type Cable with M8 male connector, 4-pin, 1,000 mm Cable material PVC Conductor cross section 0.13 mm² Cable diameter Ø 3.6 mm Circuit protection A B C D 10) Protection class III Weight 130 g Housing material Plastic, ABS Optics material Plastic, PMMA Enclosure rating IP67 Items supplied RAY10 on bracket #4101235 with P250F on bracket #4101760 Ambient operating temperature –40 °C … +60 °C 11) Ambient temperature, storage –40 °C … +70 °C UL File No. NRKH.E189383 & NRKH7.E189383 Classifications ECLASS 5.0 27270902 ECLASS 5.1.4 27270902 ECLASS 6.0 27270902 ECLASS 6.2 27270902 ECLASS 7.0 27270902 ECLASS 8.0 27270902 ECLASS 8.1 27270902 ECLASS 9.0 27270902 ECLASS 10.0 27270902 ECLASS 11.0 27270902 ECLASS 12.0 27270902 ETIM 5.0 EC002717 ETIM 6.0 EC002717 ETIM 7.0 EC002717 ETIM 8.0 EC002717 UNSPSC 16.0901 39121528
