Name: SICK 1106855 | Fotoelektrik Sensör | Royal Endüstriyel
Brand: SICK
SKU: 1106855
Price: 3200.00 TRY
Availability: InStock

Tecnichal data

Features

Specialty

Open up new fields of application in motion monitoring. SPEETEC closes the gap between tactile measuring wheel systems and complex laser Doppler sensors – and is suitable for almost all surfaces and objects thanks to the non-contact measurement.

Non-contact measurement on moving objects without measuring elements.

Class 1 laser

Safety-related parameters

MTTFd: mean time to dangerous failure

33 years

System

Light source	2 continuous beam lasers
Wave length	850 nm
Laser class	1 (IEC 60825-1:2014)
Type of light	Invisible infrared light
Typ. measurement field size (distance)	2 mm x 3 mm (at 50 mm) 8 mm x 3 mm (at 45 mm) 8 mm x 3 mm (at 55 mm)
Laser power (per laser)	0.78 mW

Performance

Nominal measuring distance

50 mm

Static mounting tolerance

Ca. ± 5 mm

Possible static measuring distance

30 … 100 mm

Direction of movement

1D, x-direction

Start/stop

Possible

Movement detection

Bidirectional

Measuring increment (µm/pulse)

100

Speed measuring range

> 0 m/s … 10 m/s

Permissible acceleration

≤ 30 m/s²

Accuracy
Measurement accuracy	0.1 %
Repeatability	0.05 %

Internal sampling rate

330 µs

Latency

2.9 ms

Electrical data

Supply voltage	12 V … 30 V
Communication interface	TTL / RS-422
Output frequency	≤ 625 kHz
Connection type	Male connector, M12, 8-pin, A-coded
Parameterization and diagnostic interface with digital input and output	No
Power consumption	< 8 W
Load current	≤ 30 mA, per channel
Reverse polarity protection	✔
Protection class	III according to DIN EN 61140
Short-circuit resistant outputs	✔
Initialization time	Max. 3 s

Mechanical data

Dimensions

140 mm x 95 mm x 32.5 mm (without plug)

Weight

400 g

Material
Housing	Aluminum
Screen	PMMA
Plug insert	PA66, copper-zinc alloy (CuZn)

Permissible angle
Permissible pitch angle	≤ ± 1.5°
Permissible yaw angle	≤ ± 1.5°
Permissible roll angle	≤ ± 10°

Ambient data

EMC

EN 61000-6-2, EN 61000-6-3

Enclosure rating

IP65 (EN 60529)

IP67 (EN 60529)

Permissible relative humidity

70 %

Temperature
Operating temperature range	0 °C … +45 °C
Storage temperature range	–32 °C … +60 °C, without package

Resistance
Resistance to shocks	30 g, 6 ms (EN 60068-2-27)
Resistance to vibration	20 g, 10 Hz … 2,000 Hz (EN 60068-2-6)

Classifications

ECLASS 5.0	27270790
ECLASS 5.1.4	27270790
ECLASS 6.0	27270790
ECLASS 6.2	27270790
ECLASS 7.0	27270790
ECLASS 8.0	27270790
ECLASS 8.1	27270790
ECLASS 9.0	27270790
ECLASS 10.0	27270790
ECLASS 11.0	27270790
ECLASS 12.0	27275201

NCV50B-11CC0100100 – 1106855
