Home Manyetik Sensörler MZ2Q-TSLPSKU0 – 1115197 🔍 MZ2Q-TSLPSKU0 – 1115197 ✉ Teklif Al Teklif Al Stok kodu: 1115197 Kategoriler: Manyetik Sensörler Marka: SICK Açıklama Tecnichal data Features Cylinder type T-slot Detection zone 0 mm … 50 mm Cylinder types with adapter Profile cylinder Tie rod cylinder Round body cylinder Dovetail groove cylinder SMC rail CDQ2 SMC rail ECDQ2 Housing length 40 mm Switching output 2 x PNP Output function NO Electrical wiring DC 4-wire Enclosure rating IP67 IO-Link functions Standard functions Adjustment Teach-in control panel Teaching in switching points 1 and 2 IO-Link Disabling teach-in pushbuttonTeaching in switching points 1 and 2Tolerance band for switching points in 5 stages Mechanics/electronics Detection zone 0 mm … 50 mm Supply voltage 15 V DC … 30 V DC Power consumption Typ. 25 mA, without load Voltage drop ≤ 2.2 V Continuous current Ia ≤ 100 mA Protection class III Hysteresis, typ. 1 mT Reproducibility ≤ 0.1 mT Reverse polarity protection Yes Short-circuit protection Yes Status indicator LED Yes Teach-in Yes Power-up pulse protection Yes Ambient operating temperature –20 °C … +75 °C Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm EMC According to EN 60947-5-2 Connection type Cable, 4-wire, 2 m Connection type Detail Cable diameter Ø 2.6 mm Bending radius With fixed installation > 5 x cable diameter For flexible use > 10 x cable diameter Cable outlet Axial Material Housing Plastic Cable PUR UL File No. NRKH.E181493 & NRKH7.E181493 Safety-related parameters MTTFD 799 years DCavg 0% TM (mission time) 20 years Communication interface Communication interface IO-Link V1.0 Communication Interface detail COM2 (38,4 kBaud) Cycle time 2.3 ms Process data length 2 Bit Process data structure Bit 0 = switching signal QL1 Bit 1 = switching signal QL2 Bit 2 … 7 = empty Classifications ECLASS 5.0 27270104 ECLASS 5.1.4 27270104 ECLASS 6.0 27270104 ECLASS 6.2 27270104 ECLASS 7.0 27270104 ECLASS 8.0 27270104 ECLASS 8.1 27270104 ECLASS 9.0 27270104 ECLASS 10.0 27270104 ECLASS 11.0 27270104 ECLASS 12.0 27274301 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC002544 UNSPSC 16.0901 39122230 İlgili ürünler MPS-032THNP0 – 1072897SICKManyetik Sensörler ₺2.200,00 Ürüne Git RZC1-04ZUS-KU0S01 – 1065397SICKManyetik Sensörler ₺850,00 Ürüne Git MZT8-2V6PSTKP0 – 1073268SICKManyetik Sensörler ₺2.200,00 Ürüne Git MZC1-4V3PO-KU0 – 1063549SICKManyetik Sensörler ₺2.200,00 Ürüne Git
Tecnichal data Features Cylinder type T-slot Detection zone 0 mm … 50 mm Cylinder types with adapter Profile cylinder Tie rod cylinder Round body cylinder Dovetail groove cylinder SMC rail CDQ2 SMC rail ECDQ2 Housing length 40 mm Switching output 2 x PNP Output function NO Electrical wiring DC 4-wire Enclosure rating IP67 IO-Link functions Standard functions Adjustment Teach-in control panel Teaching in switching points 1 and 2 IO-Link Disabling teach-in pushbuttonTeaching in switching points 1 and 2Tolerance band for switching points in 5 stages Mechanics/electronics Detection zone 0 mm … 50 mm Supply voltage 15 V DC … 30 V DC Power consumption Typ. 25 mA, without load Voltage drop ≤ 2.2 V Continuous current Ia ≤ 100 mA Protection class III Hysteresis, typ. 1 mT Reproducibility ≤ 0.1 mT Reverse polarity protection Yes Short-circuit protection Yes Status indicator LED Yes Teach-in Yes Power-up pulse protection Yes Ambient operating temperature –20 °C … +75 °C Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm EMC According to EN 60947-5-2 Connection type Cable, 4-wire, 2 m Connection type Detail Cable diameter Ø 2.6 mm Bending radius With fixed installation > 5 x cable diameter For flexible use > 10 x cable diameter Cable outlet Axial Material Housing Plastic Cable PUR UL File No. NRKH.E181493 & NRKH7.E181493 Safety-related parameters MTTFD 799 years DCavg 0% TM (mission time) 20 years Communication interface Communication interface IO-Link V1.0 Communication Interface detail COM2 (38,4 kBaud) Cycle time 2.3 ms Process data length 2 Bit Process data structure Bit 0 = switching signal QL1 Bit 1 = switching signal QL2 Bit 2 … 7 = empty Classifications ECLASS 5.0 27270104 ECLASS 5.1.4 27270104 ECLASS 6.0 27270104 ECLASS 6.2 27270104 ECLASS 7.0 27270104 ECLASS 8.0 27270104 ECLASS 8.1 27270104 ECLASS 9.0 27270104 ECLASS 10.0 27270104 ECLASS 11.0 27270104 ECLASS 12.0 27274301 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC002544 UNSPSC 16.0901 39122230
