Home Manyetik Sensörler MPS-032THNP0 – 1072897 🔍 MPS-032THNP0 – 1072897 ✉ Teklif Al Teklif Al Stok kodu: 1072897 Kategoriler: Manyetik Sensörler Marka: SICK Açıklama Tecnichal data Features Cylinder type T-slot Cylinder types with adapter Round body cylinder Profile cylinders and tie-rod cylinders Dovetail groove cylinder SMC rail CDQ2 SMC rail ECDQ2 SMC cylinders with C-slot Measuring range 32 mm Housing length 45 mm Output function Analog Electrical wiring DC 4-wire Analog output (voltage) 0 V … 10 V Analog output (current) 4 mA … 20 mA Enclosure rating IP67 Mechanics/electronics Supply voltage 15 V DC … 30 V DC Power consumption 22 mA, without load Max. load resistance ≤ 500 Ω Power Output, at 24 V Min. load resistance ≥ 2 kΩ Protection class III Time delay before availability 1.5 s Required magnetic field sensitivity, typ. 2 mT … 15 mT Resolution, typ. 0.03 % FSR (max. ≥ 0.05 mm) Linearity error, typ. 0.3 mm Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) Sampling rate, typ. 1 ms Reverse polarity protection Yes Short-circuit protection Yes Status indicator LED Yes Ambient operating temperature –20 °C … +70 °C Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm EMC According to EN 60947-5-7 Connection type Cable with M8 male connector, 4-pin, 0.3 m Connection type Detail Deep-freeze property Do not bend below 0 °C Conductor cross section 0.08 mm² Cable diameter Ø 2.6 mm Bending radius With fixed installation > 5 x cable diameter For flexible use > 10 x cable diameter Cable outlet Axial Material Housing Plastic Cable PUR UL File No. NRKH.E181493 & NRKH7.E181493 Safety-related parameters MTTFD 387 years DCavg 0 % TM (mission time) 20 years Classifications ECLASS 5.0 27270104 ECLASS 5.1.4 27270104 ECLASS 6.0 27270104 ECLASS 6.2 27270104 ECLASS 7.0 27270104 ECLASS 8.0 27270104 ECLASS 8.1 27270104 ECLASS 9.0 27270104 ECLASS 10.0 27270104 ECLASS 11.0 27270104 ECLASS 12.0 27274301 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC002544 UNSPSC 16.0901 39122230 İlgili ürünler MPS-192TLTQ0 – 1062519SICKManyetik Sensörler ₺2.200,00 Ürüne Git MZT8-2V6PSTKW0 – 1073269SICKManyetik Sensörler ₺2.200,00 Ürüne Git MPS-160TLTQ0 – 1062521SICKManyetik Sensörler ₺2.200,00 Ürüne Git MZC1-4V3PO-KU0 – 1063549SICKManyetik Sensörler ₺2.200,00 Ürüne Git
Tecnichal data Features Cylinder type T-slot Cylinder types with adapter Round body cylinder Profile cylinders and tie-rod cylinders Dovetail groove cylinder SMC rail CDQ2 SMC rail ECDQ2 SMC cylinders with C-slot Measuring range 32 mm Housing length 45 mm Output function Analog Electrical wiring DC 4-wire Analog output (voltage) 0 V … 10 V Analog output (current) 4 mA … 20 mA Enclosure rating IP67 Mechanics/electronics Supply voltage 15 V DC … 30 V DC Power consumption 22 mA, without load Max. load resistance ≤ 500 Ω Power Output, at 24 V Min. load resistance ≥ 2 kΩ Protection class III Time delay before availability 1.5 s Required magnetic field sensitivity, typ. 2 mT … 15 mT Resolution, typ. 0.03 % FSR (max. ≥ 0.05 mm) Linearity error, typ. 0.3 mm Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) Sampling rate, typ. 1 ms Reverse polarity protection Yes Short-circuit protection Yes Status indicator LED Yes Ambient operating temperature –20 °C … +70 °C Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm EMC According to EN 60947-5-7 Connection type Cable with M8 male connector, 4-pin, 0.3 m Connection type Detail Deep-freeze property Do not bend below 0 °C Conductor cross section 0.08 mm² Cable diameter Ø 2.6 mm Bending radius With fixed installation > 5 x cable diameter For flexible use > 10 x cable diameter Cable outlet Axial Material Housing Plastic Cable PUR UL File No. NRKH.E181493 & NRKH7.E181493 Safety-related parameters MTTFD 387 years DCavg 0 % TM (mission time) 20 years Classifications ECLASS 5.0 27270104 ECLASS 5.1.4 27270104 ECLASS 6.0 27270104 ECLASS 6.2 27270104 ECLASS 7.0 27270104 ECLASS 8.0 27270104 ECLASS 8.1 27270104 ECLASS 9.0 27270104 ECLASS 10.0 27270104 ECLASS 11.0 27270104 ECLASS 12.0 27274301 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC002544 UNSPSC 16.0901 39122230
