Tecnichal data
SYSTEM VOLTAGE DATASupply Voltage480V 60HzMaximum Available Fault Current5 kACIRCUIT BREAKERCircuit Breaker TypeMotor Protection Circuit BreakerAdj. Thermal Current Range (A)14.5 – 20AApplicationStandard Magnetic Trip (Fixed at 13 x le)Frame SizeFrame Size FBreaking CapacityHigh Breaking CapacityUL Listed Application Ratings
- UL 508 – Manual Motor Controller
- UL 508 Manual Self-Protected (Type E) Combination Motor Controller
SHORT CIRCUIT COORDINATIONCoordination TypeType 1OPTIONSSide Mount Shunt Trip and Undervoltage ReleaseNoneFront Mount Auxiliary and Trip ContactsNoneSide Mount Auxiliary and Trip Contacts (TESTDESC)None
