Name: Allen Bradley 140G-G2C4-C63 | Royal Endüstriyel
Brand: ALLEN BRADLEY
SKU: 140G-G2C4-C63
Price: 1500.00 TRY
Availability: InStock

Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M – Fixed Thermal/Fixed Magnetic TMF, Rated Current 63 A, 4 Pole, Interrupting Code G2 – 140G-G2C4-C63

✉ Teklif Al

Teklif Al

Technical Specs

Specifications
Bulletin Number:140G – Molded Case Circuit Breaker
Frame/Rating:G Frame (125 A)
Interrupting Rating, 50/60 Hz, 240V (kA):50
Interrupting Rating, 50/60 Hz, 480V (kA):25
Interrupting Rating, 50/60 Hz, 600V (kA):10
Breaking Capacity, 50/60 Hz, 220V (kA):65
Breaking Capacity, 50/60 Hz, 415V (kA):36
Breaking Capacity, 50/60 Hz, 440V (kA):36
Circuit Breaker Data
Device Type:140G – Molded Case Circuit Breaker
Number of Poles:4 Poles
Frame Size:G frame
Rated Current(A):63 A
Protection:T/M – Thermal Magnetic
Manufacturing
Assembly:Factory Assembled

Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M – Fixed Thermal/Fixed Magnetic TMF, Rated Current 63 A, 4 Pole, Interrupting Code G2 – 140G-G2C4-C63
