| certificates / approvals |  |
suitable for safety functions |
yes |
|---|---|
housing material |
plastic |
number of protected contact energized outputs |
2 |
type of electric connection |
cable |
cable length |
3 m |
construction type housing |
cuboid |
protected switch distance OFF |
17 mm |
cross-/short circuit identification possible |
yes |
degree of protection (IP) |
IP67 |
type of actuation |
magnet |
category (ISO 13849-1) |
4 |
|---|---|
PL (ISO 13849-1) |
Level e |
SILCL (IEC 62061) |
3 |
HFT |
1 |
TM |
20 a |
max. output current at protected output |
200 mA |
|---|---|
min. output current |
5 mA |
min. rated supply voltage at DC |
5 V |
max. rated supply voltage at DC |
48 V |
voltage type |
DC |
|---|---|
number of protected semiconductor outputs |
0 |
type of switch output |
other |
diameter sensor |
30 mm |
|---|---|
length of sensor |
32 mm |
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27270105 |
ETIM 9.0 |
EC002544 |
ETIM 8.0 |
EC002544 |
ETIM 7.0 |
EC002544 |
ETIM 6.0 |
EC002544 |
ETIM 5.0 |
EC002544 |
ETIM 4.0 |
EC002544 |
ROHS conformity status |
compliant |
|---|---|
REACH-SVHC conformity status |
compliant |
