Tecnichal data
| Number of digital inputs | 8 |
| Connector insert material | PBT |
| Width, approx | 60 mm |
| Depth, approx | 41.5 mm |
| Input pins | 5-pin |
| Cable output description | No cable |
| Material | Grey pocan |
| Input port type | DC micro quick disconnect M12 |
| Receptacle shell material | Zinc diecast with Nickel plating |
| Height, approx | 4-port: 102 mm, 6-port: 127 mm, 8-port: 152 mm |
| Wall mounting/direct mounting | Yes |
| Cable diameter | 6 mm |
| Product feature type | Standard material |
| Contact material | Gold-Plated Palladium/Nickel |
| Illumination | NPN LEDs |
| Degree of protection (IP) | IP67 |
| QD output description | No pins |
| Output style | Terminal chamber |
| Wiring configuration | Parallel-1 input/port |
| Enclosure type rating | IP67, 1200 psi (8270 kPa) washdown |
| Type of electric connection | Plug-in connection |
| Cable gland | M20 mounting thread |
| Port orientation | Ports on top of box |
| Suitable for safety functions | Yes |
