Tecnichal data
| Voltage type for actuating | AC |
| Rated control supply voltage at AC 50 Hz | 240 V |
| Rated control supply voltage at AC 60 Hz | 277 V |
| Type of electrical connection of main circuit | Screw connection |
| Number of poles | 8 |
| Continuous ampere rating | 30 A |
| Current rating for tungsten load | 20 A max. @ 3-Phase AC Poles to Load voltage 480Y |
| Current rating for ballast load | 20 A max. @ 3-Phase AC Poles to Load voltage 480Y |
| General use resistance heating | 30 A max. @ 3-Phase AC Poles to Load voltage 600V |
| Features | Multi-pole, Electrically held |
| Modular version | Yes |
| Contactor type | UL |
| Contactor size | 20 A |
| Enclosure type rating | Open |
