In combination with process temperature –196 °C … +200 °C, –1 bar … 25 bar (-100 kPa … 2,500 kPa / –14.5 psig … 362.6 psig) are possible: –1 bar … 16 bar (-100 kPa … 1,600 kPa / –14.5 psig … 232 psig)
Process temperature
–40 °C … +130 °C
RoHS certificate
✔
HART
✔
Indication
Installed
Control element
Bluetooth
Magnet pin operation
Performance
Accuracy of sensor element
≤ 1 mm
Non-repeatability
≤ 1 mm
Digital measurement resolution
< 1 mm
Analog measurement resolution
0.3 µA
Digital output temperature drift
≤ 3 mm / 10 K, max. 10 mm
Current output temperature drift
≤ 0.03% / 10 K relating to the 16 mA span or ≤ 0.3%
Deviation on current output due to digital-analog conversion
< 15 µA
Measurement cycle time
Approx. 700 ms
Step response time
≤ 3 s
MTBF
3,37*10^6 h
Display
✔
Electronics
Supply voltage
12 V DC … 35 V DC, 18 V DC … 35 V DC with illumination switched on
