Home Endüktif Sensörler IQ20-07BPPDU5S – 6072660 🔍 IQ20-07BPPDU5S – 6072660 ✉ Teklif Al Teklif Al Stok kodu: 6072660 Kategoriler: Endüktif Sensörler Marka: SICK Açıklama Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 20 mm x 32 mm x 8 mm Sensing range Sn 7 mm Safe sensing range Sa 5.67 mm Installation type Flush Switching frequency 150 Hz Connection type Cable, 4-wire, 5 m Switching output PNP Output function Complementary Electrical wiring DC 4-wire Enclosure rating IP67 Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple ≤ 10 % Voltage drop < 2.5 V Time delay before availability ≤ 20 ms Hysteresis 1 % … 15 % Reproducibility ± 5 % Temperature drift (of Sr) ± 10 % EMC According to EN 60947-5-2 Continuous current Ia ≤ 200 mA Cable material PUR Short-circuit protection ✔ Reverse polarity protection ✔ Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm Ambient operating temperature –25 °C … +70 °C Housing material Zinc diecast, GD Zn Sensing face material Plastic, PA12 UL File No. E191603 Reduction factors Note The values are reference values which may vary Stainless steel (V2A, 304) Approx. 0.7 Aluminum (Al) Approx. 0.4 Copper (Cu) Approx. 0.3 Brass (Br) Approx. 0.4 Installation note Remark Associated graphic see “Installation” A 0 mm B 20 mm C 20 mm D 21 mm E 0 mm F 60 mm Classifications ECLASS 5.0 27270101 ECLASS 5.1.4 27270101 ECLASS 6.0 27270101 ECLASS 6.2 27270101 ECLASS 7.0 27270101 ECLASS 8.0 27270101 ECLASS 8.1 27270101 ECLASS 9.0 27270101 ECLASS 10.0 27270101 ECLASS 11.0 27270101 ECLASS 12.0 27274001 ETIM 5.0 EC002714 ETIM 6.0 EC002714 ETIM 7.0 EC002714 ETIM 8.0 EC002714 UNSPSC 16.0901 39122230 İlgili ürünler 12 mm Barrel Inductive Prox Sensor – 872C-N8NP12-E5ALLEN BRADLEYEndüktif Sensörler ₺1.800,00 Ürüne Git Endüstriyel bağlantı kablosu – 871TM-B3C12-A2ALLEN BRADLEYEndüktif Sensörler ₺1.800,00 Ürüne Git Inductive Sensor – 872C-DX34-D4ALLEN BRADLEYEndüktif Sensörler ₺1.800,00 Ürüne Git Endüstriyel bağlantı kablosu – 872C-D3NP12-E2ALLEN BRADLEYEndüktif Sensörler ₺1.800,00 Ürüne Git
Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 20 mm x 32 mm x 8 mm Sensing range Sn 7 mm Safe sensing range Sa 5.67 mm Installation type Flush Switching frequency 150 Hz Connection type Cable, 4-wire, 5 m Switching output PNP Output function Complementary Electrical wiring DC 4-wire Enclosure rating IP67 Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple ≤ 10 % Voltage drop < 2.5 V Time delay before availability ≤ 20 ms Hysteresis 1 % … 15 % Reproducibility ± 5 % Temperature drift (of Sr) ± 10 % EMC According to EN 60947-5-2 Continuous current Ia ≤ 200 mA Cable material PUR Short-circuit protection ✔ Reverse polarity protection ✔ Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm Ambient operating temperature –25 °C … +70 °C Housing material Zinc diecast, GD Zn Sensing face material Plastic, PA12 UL File No. E191603 Reduction factors Note The values are reference values which may vary Stainless steel (V2A, 304) Approx. 0.7 Aluminum (Al) Approx. 0.4 Copper (Cu) Approx. 0.3 Brass (Br) Approx. 0.4 Installation note Remark Associated graphic see “Installation” A 0 mm B 20 mm C 20 mm D 21 mm E 0 mm F 60 mm Classifications ECLASS 5.0 27270101 ECLASS 5.1.4 27270101 ECLASS 6.0 27270101 ECLASS 6.2 27270101 ECLASS 7.0 27270101 ECLASS 8.0 27270101 ECLASS 8.1 27270101 ECLASS 9.0 27270101 ECLASS 10.0 27270101 ECLASS 11.0 27270101 ECLASS 12.0 27274001 ETIM 5.0 EC002714 ETIM 6.0 EC002714 ETIM 7.0 EC002714 ETIM 8.0 EC002714 UNSPSC 16.0901 39122230
