Technical Specs
Specifications
Connection:Screw Terminals
1-Phase HP (60 Hz) 115V Rating:0.5
1-Phase HP (60 Hz) 230V Rating:1.5
3-Phase HP (60 Hz) 575V Rating:7.5
Contactor Data
Terminal Type:Screw Terminals
Rated Operating Current, AC-3:9A
Coil Voltage:48-72V DC Electronic Coil
Coil Termination:Line Side
Contact Configuration:1 N.O. 0 N.C. Auxiliary Contact Configuration
Package Quantity:1
Application Data
Electrical Standards:UL
Load Data [Optional]
Utilization Category:AC-3 Squirrel-cage motor starting and stopping
Life Data [Optional]
Actual Life:Actual Life Cannot be Calculated (more information)…
Terminal Marking Positions Used
100-C or 104-C Contactor:1_
Front Mounted Auxiliary Contact:None
Left Side Auxiliary Contact:None
Right Side Auxiliary Contact:None
Interlock:None
