Number of positive action N/C solenoid monitoring contacts
2
Number of N/O solenoid monitoring contacts
0
Number of positive action N/C door monitoring contacts
1
Number of N/O door monitoring contacts
1
Number of N/C door monitoring contacts
0
Locking force Fmax
1,300 N (EN ISO 14119)
Locking force FZh
1,000 N (EN ISO 14119)
Actuation force
≥ 10 N
Retaining force
≤ 20 N
Actuation frequency
≤ 1,200 /h
Actuation directions
4
Approach speed
≤ 20 m/min
Safety-related parameters
B10d parameter
3 x 106 switching cycles (with small load)
Type
Type 2 (EN ISO 14119)
Actuator coding level
Low coding level (EN ISO 14119)
Safe state in the event of a fault
The switch has no internal fault detection and is unable to assume a safe state in the event of a fault. Fault detection is performed by the connected safety-related logic unit.
