Name: SICK 1104069 | Fotoelektrik Sensör | Royal Endüstriyel
Brand: SICK
SKU: 1104069
Price: 3200.00 TRY
Availability: InStock

Tecnichal data

Features

Functional principle

Photoelectric proximity sensor

Functional principle detail

Background suppression

Dimensions (W x H x D)

16.2 mm x 45.5 mm x 31.8 mm

Housing design (light emission)

Hybrid

Thread diameter (housing)

M18

Mounting system type

M18, head/side (24.1 … 25.4 mm)

Housing color

Blue

Sensing range max.

30 mm … 300 mm

Sensing range

30 mm … 250 mm

Type of light

Visible red light

Light source

Laser

Light spot size (distance)

2 mm (120 mm)

Wave length

655 nm

Laser class

Adjustment
Potentiometer, right	Sensing range
Potentiometer, left	None

Special applications

Detecting small objects

Special features

Signal strength light bar

Mechanics/electronics

Supply voltage

10 V DC … 30 V DC

Ripple

< 5 V_pp

Current consumption

≤ 20 mA

Switching output

PNP

Switching mode

Light switching

Switching output detail
Switching output Q1	PNP, Light switching
Switching output Q2	Not connected

Output current I_max.

≤ 100 mA

Response time

≤ 0.5 ms

Switching frequency

1,000 Hz

Connection type

Cable with connector M8, 3-pin, 150 mm

Cable material

PVC

Conductor cross section

0.2 mm²

Circuit protection

Protection class

III

Weight

18 g

Housing material

Plastic, VISTAL®

Optics material

Plastic, PMMA

Enclosure rating

IP67

IP69K

Items supplied

Fastening nut (1x), M18, plastic, black, flat

Electromagnetic compatibility (EMC)

EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.)

Ambient operating temperature

–30 °C … +55 °C

Ambient temperature, storage

–40 °C … +70 °C

UL File No.

E189383

Classifications

ECLASS 5.0	27270904
ECLASS 5.1.4	27270904
ECLASS 6.0	27270904
ECLASS 6.2	27270904
ECLASS 7.0	27270904
ECLASS 8.0	27270904
ECLASS 8.1	27270904
ECLASS 9.0	27270904
ECLASS 10.0	27270904
ECLASS 11.0	27270904
ECLASS 12.0	27270904
ETIM 5.0	EC002719
ETIM 6.0	EC002719
ETIM 7.0	EC002719
ETIM 8.0	EC002719
UNSPSC 16.0901	39121528

Connection type/pinouts

Connection type

Cable with connector M8, 3-pin, 150 mm

Connection type Detail
Conductor cross section	0.2 mm²
Cable material	PVC

Pinouts
BN 1	+ (L+)
BU 3	– (M)
BK 4	Q

HTB18L-P2B5BB – 1104069
