Home Fotoelektrik Sensörler HTB18-P1G2BLA00 – 1100040 🔍 HTB18-P1G2BLA00 – 1100040 ✉ Teklif Al Teklif Al Stok kodu: 1100040 Kategoriler: Fotoelektrik Sensörler Marka: SICK Açıklama Tecnichal data Features Functional principle Photoelectric proximity sensor Functional principle detail Background suppression Dimensions (W x H x D) 16.2 mm x 45.5 mm x 31.8 mm Housing design (light emission) Hybrid Thread diameter (housing) M18 Mounting system type M18, head/side (24.1 … 25.4 mm) Housing color Blue Sensing range max. 5 mm … 300 mm Sensing range 5 mm … 150 mm Type of light Visible red light Light source PinPoint LED Light spot size (distance) 7 mm (300 mm) Wave length 631 nm Adjustment Potentiometer, right Teach-in Potentiometer, left None Special features Signal strength light bar Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption ≤ 20 mA Switching output PNP Output function Complementary Switching mode Light/dark switching Switching output detail Switching output Q1 PNP, Light switching Switching output Q2 PNP, Dark switching Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Connection type Cable open end, 2,000 mm Cable material PVC Conductor cross section 0.2 mm² Circuit protection A B D Protection class III Weight 18 g Housing material Plastic, VISTAL® Optics material Plastic, PMMA Enclosure rating IP67 IP69K Items supplied Fastening nut (1x), M18, plastic, black, flat Electromagnetic compatibility (EMC) EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.) Ambient operating temperature –40 °C … +65 °C Ambient temperature, storage –40 °C … +75 °C UL File No. E189383 Communication interface IO-Link ✔ , V1.1 Data transmission rate 38,4 kbit/s (COM2) Cycle time 2.3 ms Process data length 16 Bit Process data structure A Bit 0 = switching signal QL1 Process data structure B Bit 0 = switching signal QL1 Diagnosis Device status Yes Quality of teach Yes Classifications ECLASS 5.0 27270904 ECLASS 5.1.4 27270904 ECLASS 6.0 27270904 ECLASS 6.2 27270904 ECLASS 7.0 27270904 ECLASS 8.0 27270904 ECLASS 8.1 27270904 ECLASS 9.0 27270904 ECLASS 10.0 27270904 ECLASS 11.0 27270904 ECLASS 12.0 27270904 ETIM 5.0 EC002719 ETIM 6.0 EC002719 ETIM 7.0 EC002719 ETIM 8.0 EC002719 UNSPSC 16.0901 39121528 Connection type/pinouts Connection type Cable open end, 2,000 mm Connection type Detail Conductor cross section 0.2 mm² Cable material PVC Pinouts BN + (L+) WH Q2 BU – (M) BK Q1/C İlgili ürünler Distance Measurement Sensor – 45DMS-B8LAT1-D4ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Endüstriyel bağlantı kablosu – 42CA-P2MNB-A2ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Endüstriyel bağlantı kablosu – 42CA-U2MPA-A2ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Photoelectric Sensors – 42AF-R1CHB1-A2ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git
Tecnichal data Features Functional principle Photoelectric proximity sensor Functional principle detail Background suppression Dimensions (W x H x D) 16.2 mm x 45.5 mm x 31.8 mm Housing design (light emission) Hybrid Thread diameter (housing) M18 Mounting system type M18, head/side (24.1 … 25.4 mm) Housing color Blue Sensing range max. 5 mm … 300 mm Sensing range 5 mm … 150 mm Type of light Visible red light Light source PinPoint LED Light spot size (distance) 7 mm (300 mm) Wave length 631 nm Adjustment Potentiometer, right Teach-in Potentiometer, left None Special features Signal strength light bar Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption ≤ 20 mA Switching output PNP Output function Complementary Switching mode Light/dark switching Switching output detail Switching output Q1 PNP, Light switching Switching output Q2 PNP, Dark switching Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Connection type Cable open end, 2,000 mm Cable material PVC Conductor cross section 0.2 mm² Circuit protection A B D Protection class III Weight 18 g Housing material Plastic, VISTAL® Optics material Plastic, PMMA Enclosure rating IP67 IP69K Items supplied Fastening nut (1x), M18, plastic, black, flat Electromagnetic compatibility (EMC) EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.) Ambient operating temperature –40 °C … +65 °C Ambient temperature, storage –40 °C … +75 °C UL File No. E189383 Communication interface IO-Link ✔ , V1.1 Data transmission rate 38,4 kbit/s (COM2) Cycle time 2.3 ms Process data length 16 Bit Process data structure A Bit 0 = switching signal QL1 Process data structure B Bit 0 = switching signal QL1 Diagnosis Device status Yes Quality of teach Yes Classifications ECLASS 5.0 27270904 ECLASS 5.1.4 27270904 ECLASS 6.0 27270904 ECLASS 6.2 27270904 ECLASS 7.0 27270904 ECLASS 8.0 27270904 ECLASS 8.1 27270904 ECLASS 9.0 27270904 ECLASS 10.0 27270904 ECLASS 11.0 27270904 ECLASS 12.0 27270904 ETIM 5.0 EC002719 ETIM 6.0 EC002719 ETIM 7.0 EC002719 ETIM 8.0 EC002719 UNSPSC 16.0901 39121528 Connection type/pinouts Connection type Cable open end, 2,000 mm Connection type Detail Conductor cross section 0.2 mm² Cable material PVC Pinouts BN + (L+) WH Q2 BU – (M) BK Q1/C
