Cable with male connector, micro (1/2”-20), 4-pin, 150 mm
Cable material
PVC
Conductor cross section
0.2 mm²
Circuit protection
A
B
D
Protection class
II
Weight
18 g
Housing material
Plastic, VISTAL®
Optics material
Plastic, PMMA
Enclosure rating
IP67
IP69K
Items supplied
Fastening nut (1x), M18, plastic, black, flat
Electromagnetic compatibility (EMC)
EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.)
Ambient operating temperature
–40 °C … +70 °C
Ambient temperature, storage
–40 °C … +75 °C
UL File No.
E189383
Classifications
ECLASS 5.0
27270901
ECLASS 5.1.4
27270901
ECLASS 6.0
27270901
ECLASS 6.2
27270901
ECLASS 7.0
27270901
ECLASS 8.0
27270901
ECLASS 8.1
27270901
ECLASS 9.0
27270901
ECLASS 10.0
27270901
ECLASS 11.0
27270901
ECLASS 12.0
27270901
ETIM 5.0
EC002716
ETIM 6.0
EC002716
ETIM 7.0
EC002716
ETIM 8.0
EC002716
UNSPSC 16.0901
39121528
Connection type/pinouts
Connection type
Cable with male connector, micro (1/2”-20), 4-pin, 150 mm
