Home Fotoelektrik Sensörler HL18-P4A3BI – 1098121 🔍 HL18-P4A3BI – 1098121 ✉ Teklif Al Teklif Al Stok kodu: 1098121 Kategoriler: Fotoelektrik Sensörler Marka: SICK Açıklama Tecnichal data Features Functional principle Photoelectric retro-reflective sensor Functional principle detail Dual lens Dimensions (W x H x D) 16.2 mm x 48.5 mm x 31.8 mm Housing design (light emission) Hybrid Thread diameter (housing) M18 Mounting system type M18, head/side (24.1 … 25.4 mm) Housing color Blue Sensing range max. 0.03 m … 6.5 m Sensing range 0.03 m … 5 m Type of light Visible red light Light source PinPoint LED Light spot size (distance) 130 mm x 260 mm (6.5 m) Wave length 631 nm Adjustment Potentiometer, right On delay, adjustable: 0 … 2 s Potentiometer, left Light/dark switching Special features Signal strength light bar Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption ≤ 20 mA Switching output PNP Output function Complementary Switching mode Light/dark switching Switching output detail Switching output Q1 PNP, Light switching Switching output Q2 PNP, Dark switching Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Time functions On delay Connection type Male connector M12, 4-pin Circuit protection A B D Protection class III Weight 18 g Polarisation filter ✔ Housing material Plastic, VISTAL® Optics material Plastic, PMMA Enclosure rating IP67 IP69K Items supplied Fastening nut (1x), M18, plastic, black, flat Electromagnetic compatibility (EMC) EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.) Ambient operating temperature –40 °C … +70 °C Ambient temperature, storage –40 °C … +75 °C UL File No. E189383 Classifications ECLASS 5.0 27270902 ECLASS 5.1.4 27270902 ECLASS 6.0 27270902 ECLASS 6.2 27270902 ECLASS 7.0 27270902 ECLASS 8.0 27270902 ECLASS 8.1 27270902 ECLASS 9.0 27270902 ECLASS 10.0 27270902 ECLASS 11.0 27270902 ECLASS 12.0 27270902 ETIM 5.0 EC002717 ETIM 6.0 EC002717 ETIM 7.0 EC002717 ETIM 8.0 EC002717 UNSPSC 16.0901 39121528 Connection type/pinouts Connection type Male connector M12, 4-pin Pinouts BN 1 + (L+) WH 2 Q2 BU 3 – (M) BK 4 Q1 İlgili ürünler 18 mm Cylindrical Sensor, 18 mm Cylindrical, Transmitted Beam Source, Infrared, Not Adjustable Sensitivity, Transmitted Beam Source, DC Transmitted Beam Emitter, 4 Pin Micro Quick Disconnect, Plastic, 18mm Mount, 3 mm Minimum Sensing Distance, 16000 mm Op – 42CA-E1EZB1-D4ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Endüstriyel bağlantı kablosu – 42CA-P2MNB-A2ALLEN BRADLEYFotoelektrik Sensörler ₺3.200,00 Ürüne Git Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, NPN Output, 80 mm Gap, Plastic, 4 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LNA3-P4ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git Photoelectric Sensor, Fork Style, Visible Red LED, Light Operate – Dark Operate Selectable Output, NPN Output, 80 mm Gap, Plastic, 3 Pin Pico M8 Quick Disconnect Connector, Teachable Sensitivity – 45LSP-2LNA3-P3ALLEN BRADLEYFotoelektrik Sensörler ₺450,00 Ürüne Git
Tecnichal data Features Functional principle Photoelectric retro-reflective sensor Functional principle detail Dual lens Dimensions (W x H x D) 16.2 mm x 48.5 mm x 31.8 mm Housing design (light emission) Hybrid Thread diameter (housing) M18 Mounting system type M18, head/side (24.1 … 25.4 mm) Housing color Blue Sensing range max. 0.03 m … 6.5 m Sensing range 0.03 m … 5 m Type of light Visible red light Light source PinPoint LED Light spot size (distance) 130 mm x 260 mm (6.5 m) Wave length 631 nm Adjustment Potentiometer, right On delay, adjustable: 0 … 2 s Potentiometer, left Light/dark switching Special features Signal strength light bar Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple < 5 Vpp Current consumption ≤ 20 mA Switching output PNP Output function Complementary Switching mode Light/dark switching Switching output detail Switching output Q1 PNP, Light switching Switching output Q2 PNP, Dark switching Output current Imax. ≤ 100 mA Response time ≤ 0.5 ms Switching frequency 1,000 Hz Time functions On delay Connection type Male connector M12, 4-pin Circuit protection A B D Protection class III Weight 18 g Polarisation filter ✔ Housing material Plastic, VISTAL® Optics material Plastic, PMMA Enclosure rating IP67 IP69K Items supplied Fastening nut (1x), M18, plastic, black, flat Electromagnetic compatibility (EMC) EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.) Ambient operating temperature –40 °C … +70 °C Ambient temperature, storage –40 °C … +75 °C UL File No. E189383 Classifications ECLASS 5.0 27270902 ECLASS 5.1.4 27270902 ECLASS 6.0 27270902 ECLASS 6.2 27270902 ECLASS 7.0 27270902 ECLASS 8.0 27270902 ECLASS 8.1 27270902 ECLASS 9.0 27270902 ECLASS 10.0 27270902 ECLASS 11.0 27270902 ECLASS 12.0 27270902 ETIM 5.0 EC002717 ETIM 6.0 EC002717 ETIM 7.0 EC002717 ETIM 8.0 EC002717 UNSPSC 16.0901 39121528 Connection type/pinouts Connection type Male connector M12, 4-pin Pinouts BN 1 + (L+) WH 2 Q2 BU 3 – (M) BK 4 Q1
