Functional principle

Photoelectric retro-reflective sensor

Functional principle detail

Dual lens

Dimensions (W x H x D)

16.2 mm x 45.5 mm x 31.8 mm

Housing design (light emission)

Hybrid

Thread diameter (housing)

M18

Mounting system type

M18, head/side (24.1 … 25.4 mm)

Housing color

Blue

Sensing range max.

0.03 m … 6.5 m

Sensing range

0.03 m … 5 m

Type of light

Visible red light

Light source

PinPoint LED

Light spot size (distance)

130 mm x 260 mm (6.5 m)

Wave length

631 nm

Adjustment
Potentiometer, right	Teach-in
Potentiometer, left	None

Special features

Signal strength light bar

Mechanics/electronics

Supply voltage

10 V DC … 30 V DC

Ripple

< 5 V_pp

Current consumption

≤ 20 mA

Switching output

Push-pull: PNP/NPN

Output function

Complementary

Switching mode

Light/dark switching

Switching output detail
Switching output Q1	Push-pull: PNP/NPN, Light switching
Switching output Q2	Push-pull: PNP/NPN, Dark switching

Output current I_max.

≤ 100 mA

Response time

≤ 0.5 ms

Switching frequency

1,000 Hz

Connection type

Cable open end, 2,000 mm

Cable material

PVC

Conductor cross section

0.2 mm²

Circuit protection

Protection class

III

Weight

18 g

Polarisation filter

✔

Housing material

Plastic, VISTAL®

Optics material

Plastic, PMMA

Enclosure rating

IP67

IP69K

Items supplied

Fastening nut (1x), M18, plastic, black, flat

Electromagnetic compatibility (EMC)

EN 60947-5-2 (The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residential area.)

Ambient operating temperature

–40 °C … +70 °C

Ambient temperature, storage

–40 °C … +75 °C

UL File No.

E189383

Communication interface

IO-Link	✔ , V1.1
Data transmission rate	38,4 kbit/s (COM2)
Cycle time	2.3 ms
Process data length	16 Bit

Process data structure A

Bit 0 = switching signal Q_L1

Process data structure B

Bit 0 = switching signal Q_L1

Diagnosis

Device status	Yes
Quality of teach	Yes
Quality of run	Yes, Contamination display

Classifications

ECLASS 5.0	27270902
ECLASS 5.1.4	27270902
ECLASS 6.0	27270902
ECLASS 6.2	27270902
ECLASS 7.0	27270902
ECLASS 8.0	27270902
ECLASS 8.1	27270902
ECLASS 9.0	27270902
ECLASS 10.0	27270902
ECLASS 11.0	27270902
ECLASS 12.0	27270902
ETIM 5.0	EC002717
ETIM 6.0	EC002717
ETIM 7.0	EC002717
ETIM 8.0	EC002717
UNSPSC 16.0901	39121528

Connection type/pinouts

Connection type

Cable open end, 2,000 mm

Connection type Detail
Conductor cross section	0.2 mm²
Cable material	PVC

Pinouts
BN	+ (L+)
WH	Q₂
BU	– (M)
BK	Q₁/C

HL18-F1G3BLA00 – 1100054
