Home Diğer (Montaj / Aksesuar) ETL70-0KA4 – 1116913 🔍 ETL70-0KA4 – 1116913 ✉ Teklif Al Teklif Al Stok kodu: 1116913 Kategoriler: Diğer (Montaj / Aksesuar) Marka: SICK Açıklama Tecnichal data Features Items supplied Magnetic tape not included with delivery Performance Measuring range 0 mm … 16,384 mm Resolution 1 µm Length of period 2 mm Traversing speed 4.5 m/s up to which the absolute position can be reliably produced Repeatability < 1 µm System accuracy ± 10 µm Max. reading distance 0.8 mm Interfaces Communication interface HIPERFACE DSL® Electrical data Supply voltage 7 V DC … 12 V DC Current consumption < 200 mA Connection type Male connector, M12, 4-pin, universal Status display RGB LED Mechanical data Dimensions See dimensional drawing Scope of delivery Magnetic tape not included with delivery Read head material Zinc diecast Ambient data EMC According to EN 61000-6-2 and EN 61000-6-3 Enclosure rating IP67, with mating connector inserted (IEC 60529) Operating temperature range –30 °C … +85 °C Storage temperature range –40 °C … +85 °C, without package Permissible relative humidity 100 %, condensation permitted Resistance to shocks 500 m/s², 11 ms (EN 60068-2-27) Resistance to vibration 100 m/s², 10 Hz … 2,000 Hz (EN 60068-2-6) Classifications eCl@ss 5.0 27270705 eCl@ss 5.1.4 27270705 eCl@ss 6.0 27270705 eCl@ss 6.2 27270705 eCl@ss 7.0 27270705 eCl@ss 8.0 27270705 eCl@ss 8.1 27270705 eCl@ss 9.0 27270705 eCl@ss 10.0 27270705 eCl@ss 11.0 27270705 eCl@ss 12.0 27273902 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC001486 UNSPSC 16.0901 41111613 İlgili ürünler IE-SFP/1250-ED MM850-LC – SFP-GMM-550AdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git IE-SFP/1250-ED SSBX-SM1490-LC – 808-38728AdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git SFP+-10G-ZR, 1550nm, SM, 80km – 40 85? – SFP-XSM-LCI-80KAdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git IE-SFP/1250-ED SSLX-SM1310/PLUS-SC – SFP-GSS-40KTXAdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git
Tecnichal data Features Items supplied Magnetic tape not included with delivery Performance Measuring range 0 mm … 16,384 mm Resolution 1 µm Length of period 2 mm Traversing speed 4.5 m/s up to which the absolute position can be reliably produced Repeatability < 1 µm System accuracy ± 10 µm Max. reading distance 0.8 mm Interfaces Communication interface HIPERFACE DSL® Electrical data Supply voltage 7 V DC … 12 V DC Current consumption < 200 mA Connection type Male connector, M12, 4-pin, universal Status display RGB LED Mechanical data Dimensions See dimensional drawing Scope of delivery Magnetic tape not included with delivery Read head material Zinc diecast Ambient data EMC According to EN 61000-6-2 and EN 61000-6-3 Enclosure rating IP67, with mating connector inserted (IEC 60529) Operating temperature range –30 °C … +85 °C Storage temperature range –40 °C … +85 °C, without package Permissible relative humidity 100 %, condensation permitted Resistance to shocks 500 m/s², 11 ms (EN 60068-2-27) Resistance to vibration 100 m/s², 10 Hz … 2,000 Hz (EN 60068-2-6) Classifications eCl@ss 5.0 27270705 eCl@ss 5.1.4 27270705 eCl@ss 6.0 27270705 eCl@ss 6.2 27270705 eCl@ss 7.0 27270705 eCl@ss 8.0 27270705 eCl@ss 8.1 27270705 eCl@ss 9.0 27270705 eCl@ss 10.0 27270705 eCl@ss 11.0 27270705 eCl@ss 12.0 27273902 ETIM 5.0 EC002544 ETIM 6.0 EC002544 ETIM 7.0 EC002544 ETIM 8.0 EC001486 UNSPSC 16.0901 41111613
