Tecnichal data
| Voltage type for actuating | DC |
| Interface | No |
| Rated control supply voltage at DC | 110 V |
| Rated control supply voltage at AC 50 Hz | 0 V |
| Rated control supply voltage at AC 60 Hz | 0 V |
| Mounting method | DIN-rail/screw |
| Rated frequency | 50/60 Hz, DC |
| Electrical life cycle | Auxiliary/pneumatic timer contact (front mounted): 1500000 @ 240V/3 A, AC-15 |
| Contact rating | Side mounted auxiliary contacts: NEMA A600, Q600 |
| With LED indication | No |
| Rated impulse strength (Uimp) | 6 kV |
| Operating time, closing delay | 25 ms |
| Weight | 390 g, AC coil |
| Connection type | Screw terminals |
| Operating time, opening delay | 70…125 ms with external diode |
| Shock resistance | IEC 60068-2: half sinusoidal shock 11 ms, 30 G (in 3 directions) |
| Mechanical life operations | 15000000, Auxiliary/pneumatic timer contact (front mounted): 5000000 |
| Suitable for manual operation | No |
| Vibration resistance | IEC 60068-2: static >2 G, in normal position no malfunction <5 G |
| Altitude | 2000 m above mean sea level, per IEC 60 947-4 |
| Ambient temperature | Storage: -55…80 ðC (-67…176 ðF) |
