Tecnichal data
| Number of poles | 4 |
| Operating temperature | -20 ðC |
| List of degrees of protection | IP67 and IP69K |
| Second end conductors | Same as first end |
| First end connector style | Female, straight (internal threads, except mini receptacles) |
| Cable diameter | 2 core cable: 6 mm, 3 core cable: 6 mm, 4 core cable: 7 mm, 5 core cable: 8 mm, 6 core cable: 8 mm |
| Cable type | PVC cable, yellow, unshielded, 18 AWG |
| Material | Coupling nut: Epoxy-coated Zinc, housing: molded oil-resistant TPE, contact: Gold-plated Palladium/Nickel |
| Bend radius | 10 x diameter |
| Rated voltage | 300 V |
| Cable rating | UL AWM style 2661 VW-1 105 ðC 300V, CSA AWM A/B I/II 80 ðC 300V FT1, UV oil and water resistant |
| With shield connection | No |
| Cable length | 1828.8 mm |
| Length | Connector: 61.8 mm |
| Special characteristic | Standard |
| Second end termination style | Male, straight (internal threads) |
| Second end termination type | Mini |
| Product type feature | Standard- Epoxy coated Zinc for DC micro, AC micro, mini QD with 2-6 pins, Standard-Nickel plated brass for pico, Standard-aluminum with clear sealant for mini QD with 7-12 pins |
| Material of contact surface | Gold |
| Material housing | Plastic |
| Type of plug-in contact, inner side | Female (bus) |
| Mounting method | Freely positionable |
