Tecnichal data
| Number of poles | 4 |
| Degree of protection (IP), mounted | IP69K |
| Operating temperature | -50 ðC |
| Number of pins | 4-pins |
| Second end conductors | Same as first end |
| Enclosure type rating | IP67, NEMA 6P, 1200 psi (8270 kPa) washdown, IP69K |
| First end connector style | Male, straight (external threads) |
| Cable type | Allen-Bradley toughlink TPE or toughweld CPE yellow jacket, 18 or 22 AWG conductors, 300V |
| Material | Coupling nut: Epoxy-coated Zinc, Molded oil-resistant santoprene body, Contact: Gold over Nickel-plated Brass |
| Bend radius | 10 x diameter |
| Rated voltage | 250 V |
| Rated current In | 3 A |
| Assembly rating | 3 A @ 250V |
| Cable rating | Toughlink: UL AWM style 20328 600V VW-1 105 ðC to -50 ðC water resistant, CSA AWM I/II A/B 105 ðC 600V FT2, Toughweld: UL -50C SJOOW 90 ðC dry and 60 ðC water resistant, CSA -50 ðC SJOOW 90 ðC FT1 |
| With shield connection | No |
| Cable length | 2000 mm |
| Second end termination style | No connector |
| Second end termination type | Cable – IEC standard color code |
| Diameter, approx | Connector: 14 mm (0.56 inch) @ straight male |
| Length, approx | Connector: 50.8 mm (2.0 inch) @ straight male |
| Height, approx | Connector: 31.8 mm (1.25 inch) @ right angle male |
| Product type feature | Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pins, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pins |
| Diameter | Toughlink: 8 mm (0.32 inch), Toughweld: 9 mm (0.35 inch) |
| Material of contact surface | Gold |
| Material housing | Plastic |
| Type of plug-in contact, outer side | Male (plug) |
| Mounting method | Freely positionable |
