Technical Specs
Specifications
Sensing Beam:Infrared LED
Sensing Range:100mm (3.9in)
Type:RightSight Background Suppression
Model Selection For Rightsight
Model Selection Information:Selection for RightSight Standard
Photoelectric Sensor Data
Sensing Mode:Background Suppression
Light Source:Infrared LED
Maximum Sensing Distance:100mm (3.9in)
Operating Voltage/Mode:DC – 2 Complementary LO/DO Outputs
Output Type:Sink (NPN)
Sensitivity Adjustment:No Adjustment
Connection Type:2m (6.5ft) cable
Response Time:1 ms
Voltage Rating:10.8…30V DC
IO Link Enabled:No
