Tecnichal data
| Width sensor | 20 mm |
| Degree of protection (IP) | IP65 |
| Height of sensor | 70 mm |
| Length of sensor | 40 mm |
| Operating distance, max | 2000 mm |
| Sensing mode | Light-/dark switching |
| Shock | IEC 60947-5-2: 30 G with 1 ms pulse duration, meets or exceeds |
| Vibration | IEC 60947-5-2: 10…55 Hz, 1 mm amplitude, meets or exceeds |
| Wavelength of the sensor | 880 nm |
| Response time | 2 ms |
| Max. output current | 100 mA |
| Voltage type | DC |
| Operating distance | 2000 mm |
| Rated control supply voltage at DC | 12 V |
| Type of switching output | PNP/NPN |
| Type of light | Infrared light |
| Current consumption, max | 33 mA |
| Leakage current, max | 0.1 mA |
| Sensitivity adjustment | 5-turn potentiometer |
| Housing material | Polyarylate |
| Protection type | Short circuit |
| LED status | Red OFF – Output OFF Red ON – Output ON (LED is ON when sensor is in light operate (LO) mode and a target is detected, LED is OFF when the sensor is in dark operate (DO) mode and the target is detected) |
| Number of protected semiconductor outputs | 1 |
| Setting procedure | Manual adjustment |
| Triangulation | Background fade-out |
| Material housing | Plastic |
| Type of electric connection | Cable |
| Construction type housing | Cuboid |
| Lens material | Polyarylate |
| Connection type | 2 m cable |
| Material of optical surface | Plastic |
| Field of view | 1.7 ð |
| Operating temperature | -25 ðC |
| Relative humidity | 35 to 85 % |
| Ambient light immunity | Incandescent light: 3000 lux, Sunlight: 10000 lux |
