Tecnichal data
| Category | 5E |
| Length | 7 m |
| Type of connector connection 1 | M12 |
| Cable outer diameter | 5.6 mm |
| Length, approx | 47 mm |
| Crossover | Standard |
| Number of conductors | 4 conductors (2-pair) |
| Secondary end connector | RJ45 connector |
| Cable type | Teal, unshielded twisted pair, TPE, high-flex, 24 AWG |
| Material | Coupling nut: Nickel-plated brass, housing: polyurethane (PUR), contact: Gold-plated brass |
| Material connector housing, connection 1 | Plastic |
| Special characteristic | Standard |
| Mounting | Front-mount |
| Bend radius | 10 x cable diameter |
| AWG-size | 24 |
| Voltage | 300 V |
| Cable bandwidth | 100BASE-TX, 100 Mbit/s, IEEE 802.3 fast ethernet over copper wiring |
| Cable rating | Weld splatter, sunlight, and oil resistant, UL CM, CMX, c-UL CM, TIA 568B |
| Degree of protection (IP) | IP67 |
| Operating temperature | ‘-40 to 75 ðC |
| Second end description | Straight male |
| First end description | Straight male |
