Tecnichal data
| Degree of protection (NEMA) | 13 |
| Relative humidity | Deviceboxââ¢, round media: 5…95% (noncondensing) |
| Operating temperature | -25 ðC |
| Storage temperature | -40 ðC |
| Number of drop ports | 4 drop connectors |
| Assembly rating | Deviceboxââ¢, round media: 24V, 8 A |
| Material | Deviceboxââ¢, round media: Black Polymer |
| Enclosure type rating | Deviceboxââ¢, round media: NEMA 3, 4X, 12 and 13, 1200 psi (8270 kPa) washdown |
| Drop connector type | Cable glands designed for use with devicenet thin cable, drop cable connection via terminal block connectors |
| Trunk connection | Cable glands designed for use with devicenet thin cable, trunk cable connection via terminal block connectors |
| Keyway orientation | Standard key location |
| Bulletin number | Tap devices used to provide drop connections, allowing connection of DeviceNet products to a DeviceNet trunk |
| Current, max | Deviceboxââ¢, round media, thick: 8 A max. total current, (7.5 A max. per trunk) |
| With LED indication | No |
| Material of contact surface | Gold |
| Colour housing | Black |
| Special characteristic | Standard material: Epoxy-coated Zinc coupling nuts |
