Tecnichal data
| Number of poles | 5 |
| Degree of protection (IP), mounted | IP67 |
| Number of pins | Standard 5-pin |
| Second end conductors | Standard 5-pin |
| Number of conductors | 1 pair 22 AWG, 1 pair 24 AWG and drain |
| Enclosure type rating | NEMA 1, 2, 3, 4, 6P, 12, 13, IP67, 1200 psi (8720 kPa) washdown |
| First end connector style | Micro, straight female |
| Cable diameter | 6.9 mm (0.27 inch) |
| Cable type | Thin media, grey PVC |
| Material | Coupling nut: Epoxy-coated Zinc, jacket: Yellow CPE (chemical resistant) or grey PVC, contact, mini: Gold-plated machined Brass, contact, micro: Gold over Nickelââ¬plated Brass |
| Bend radius | 10 x diameter |
| Cable length | 5000 mm |
| Special characteristic | Standard – Epoxy coated Zinc |
| Second end termination style | Micro, straight male |
| Material of contact surface | Gold |
| Current, max | 4 A |
| Cable details | Standard passive cable |
| Assembly rating | 250V, 4 A |
| Cable rating | Grey PVC: UL CL2 or CMG 75 ðC (167 ðF) or AWM 600V or c(UL) CMG or AWM I/II 80 ðC (176 ðF) 300V FT4, grey high-flex PVC: UL CL2 75 ðC (167 ðF) or AWM 20201 80 ðC (176 ðF) 600V or CSA AWM I/II 80 ðC (176 ðF) 600V FT4, yellow CPE: UL- CL2 or CM 75 ðC (167 ð |
| Cable temperature | -20 ðC |
