Tecnichal data
| Supply voltage DC | 24 V |
| Operating current, max | 2 A |
| Rated current | 2 A fixed |
| Voltage type of supply voltage | DC |
| Degree of protection (IP) | IP20 |
| Width | 12.5 mm |
| Height | 98.5 mm |
| Weight per module | Approx. 0.13 lb |
| Terminal wire gauge | Push-in terminal PT10: AWG20…AWG8 (0.5mmò to 10mmò), Push-in terminal PT2.5: AWG24…AWG14 (0.14mmò to 2.5mmò) |
| Depth | 80 mm |
| Termination type | Push-in |
| No of channels | 1 |
| Degree of pollution | 2 |
| Operating temperature | -25 ðC |
| Storage temperature | -40 ðC |
| Humidity / damp heat | 96 hrs / 95% climate class 3K3 |
