Home Diğer (Montaj / Aksesuar) E100-A2A22S25A SAFETY Switch – 6049337 🔍 E100-A2A22S25A SAFETY Switch – 6049337 ✉ Teklif Al Teklif Al Stok kodu: 6049337 Kategoriler: Diğer (Montaj / Aksesuar) Marka: SICK Açıklama Tecnichal data Features Number of positive action N/C contacts 2 Number of N/O contacts 2 Actuation directions 1 Safety-related parameters B10d parameter 5 x 105 switching cycles (with small load) Safe state in the event of a fault The switch has no internal fault detection and is unable to assume a safe state in the event of a fault. Fault detection is performed by the connected safety-related logic unit. Functions Safe series connection None, only individual wiring (with diagnostics) Interfaces Type of connection cable Straight Connection type Cable open end Length of cable 25 m Cable diameter 8 mm Conductor cross section 8 x 0.34 mm² Bend radius (with fixed installation) > 7.5 x cable diameter Bend radius (with moving cable) > 15 x cable diameter Cable material PUR Conductor material Copper Electrical data Switching principle Slow action switching element Number of positive action N/C contacts 2 Number of N/O contacts 2 Usage category AC-15/DC-13 (EN 60947-5-1) Rated operating current (voltage) 2 A (230 V AC) 2 A (24 V DC) Rated insulation voltage Ui 250 V Rated impulse withstand voltage Uimp 2,500 V Short-circuit protection 2 A gG Switching voltage ≥ 12 V DC Switching current (switching voltage) ≥ 1 mA (24 V DC) Mechanical data Dimensions 64 mm x 132 mm Weight 2.5 kg Housing material Plastic Mechanical life 1 x 105 switching cycles Ambient data Enclosure rating IP67 (EN 60529) Ambient operating temperature –5 °C … +50 °C Storage temperature –5 °C … +50 °C Classifications eCl@ss 5.0 27371238 eCl@ss 5.1.4 27371238 eCl@ss 6.0 27371238 eCl@ss 6.2 27371238 eCl@ss 7.0 27371238 eCl@ss 8.0 27371238 eCl@ss 8.1 27371238 eCl@ss 9.0 27371238 eCl@ss 10.0 27371238 eCl@ss 11.0 27371238 eCl@ss 12.0 27371238 ETIM 5.0 EC002571 ETIM 6.0 EC002571 ETIM 7.0 EC002571 ETIM 8.0 EC002571 UNSPSC 16.0901 39122205 İlgili ürünler IE-SFP/1250-ED SSBX-SM1490/PLUS-LC – 808-38730AdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git IE-SFP/1250-ED SSLX-SM1310/PLUS-SC – 808-38223AdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git IE-SFP/1250-ED MM850-LC – 808-38201AdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git SFP+-10G-ELR-IT, 1310nm, SM, 20km – 40 8 – SFP-XSM-LCI-20KAdvantechDiğer (Montaj / Aksesuar) ₺850,00 Ürüne Git
Tecnichal data Features Number of positive action N/C contacts 2 Number of N/O contacts 2 Actuation directions 1 Safety-related parameters B10d parameter 5 x 105 switching cycles (with small load) Safe state in the event of a fault The switch has no internal fault detection and is unable to assume a safe state in the event of a fault. Fault detection is performed by the connected safety-related logic unit. Functions Safe series connection None, only individual wiring (with diagnostics) Interfaces Type of connection cable Straight Connection type Cable open end Length of cable 25 m Cable diameter 8 mm Conductor cross section 8 x 0.34 mm² Bend radius (with fixed installation) > 7.5 x cable diameter Bend radius (with moving cable) > 15 x cable diameter Cable material PUR Conductor material Copper Electrical data Switching principle Slow action switching element Number of positive action N/C contacts 2 Number of N/O contacts 2 Usage category AC-15/DC-13 (EN 60947-5-1) Rated operating current (voltage) 2 A (230 V AC) 2 A (24 V DC) Rated insulation voltage Ui 250 V Rated impulse withstand voltage Uimp 2,500 V Short-circuit protection 2 A gG Switching voltage ≥ 12 V DC Switching current (switching voltage) ≥ 1 mA (24 V DC) Mechanical data Dimensions 64 mm x 132 mm Weight 2.5 kg Housing material Plastic Mechanical life 1 x 105 switching cycles Ambient data Enclosure rating IP67 (EN 60529) Ambient operating temperature –5 °C … +50 °C Storage temperature –5 °C … +50 °C Classifications eCl@ss 5.0 27371238 eCl@ss 5.1.4 27371238 eCl@ss 6.0 27371238 eCl@ss 6.2 27371238 eCl@ss 7.0 27371238 eCl@ss 8.0 27371238 eCl@ss 8.1 27371238 eCl@ss 9.0 27371238 eCl@ss 10.0 27371238 eCl@ss 11.0 27371238 eCl@ss 12.0 27371238 ETIM 5.0 EC002571 ETIM 6.0 EC002571 ETIM 7.0 EC002571 ETIM 8.0 EC002571 UNSPSC 16.0901 39122205
