EN ISO 13849-1:2015, IEC TS 62998-1:2019, EN ISO 13482:2014, ANSI/ITSDF B56.5:2012
Performance
Safety-related measuring range
50 mm … 8,500 mm, 90% remission factor
50 mm … 4,500 mm, 20% remission
50 mm … 3,000 mm, 10% remission
50 mm … 2,000 mm, 6% remission factor
Target
Natural objects
Resolution
1 mm
Systematic error
< 25 mm
Statistical error
< 25 mm
Response time
15 ms … 50 ms
Light source
Laser, red visible red light
Laser class
2 (IEC 60825-1:2014, EN 60825-1:2014)
Typ. light spot size (distance)
15 mm x 15 mm (at 2 m)
Additional function
Adjustable speed: slow and medium, teach-in of analog output and invertible analog output, Configurable Q2 output: current output / digital output, Switching mode: Distance to Object (DtO) / switching window / object between sensor and background (ObSB), teach-in of digital output, Multifunctional input: laser off / deactivated
Interfaces
IO-Link
✔ , V1.1
Function
Process data
Data transmission rate
38,4 kbit/s (COM2)
Digital output
Number
1 … 2
Type
Push-pull: PNP/NPN
Function
Configurable Q2 output: analog output / digital output
