Approx. 800 g (with mounting bracket: approx. 1,600 g)
Current consumption
At 24 V DC < 1,000 mA
Dimensions (W x H x D)
69.4 mm x 82.5 mm x 100.2 mm
Modulation frequency
Fix
Enclosure rating
IP65
Protection class
III
Safety-related parameters
MTTFD
101 years
DCavg
0%
Performance
Measurement range min … max:
0.15 m … 100 m, on “diamond grade” reflective tape
Target
Reflector
Resolution
0.1 mm, 0.125 mm, 1 mm, 10 mm, 100 mm, freely adjustable
Repeatability
0.5 mm
Accuracy
± 2 mm
Response time
2 ms
Measurement cycle time
1 ms
Output time
1 ms
Light source
Laser, red visible red light
Laser class
2, complies with 21 CFR 1040.10 and 1040.11 except for the conformance according to “Laser Notice No. 50” from June 24, 2007 (IEC 60825-1:2014, EN 60825-1:2014)
Typ. light spot size (distance)
5 mm + (2 mm x distance in m)
Max. movement speed
15 m/s
Acceleration (max.)
≤ 15 m/s²
Heating
✔
Interfaces
PROFINET
✔
SSI
✔
Digital output
Number
2
Type
Push-pull: PNP/NPN
Function
Distance: Distance switching output
Speed; Speed output
Service: Warning message as the sensor ages, if the damping value is exceeded (for example when contaminated, if the permitted interior device temperature is exceeded or undercut, if the measured value has a plausibility error, if the laser is not ready for operation, if the heating is switched on
