Home Kapasitif Sensörler CQF16-06EPOEW1 – 6068623 🔍 CQF16-06EPOEW1 – 6068623 ✉ Teklif Al Teklif Al Stok kodu: 6068623 Kategoriler: Kapasitif Sensörler Marka: SICK Açıklama Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 16 mm x 34 mm x 8 mm Sensing range Sn 0.5 mm … 6 mm Installation type Flush Non-flush Switching frequency 10 Hz Connection type Cable, 4-wire, 2 m Switching output PNP Output function NC Electrical wiring DC 4-wire Adjustment Teach-in by wire (full or empty) Enclosure rating IP67, IP68, IP69K Special features Detection of water-based liquids up to a conductivity of 50 mS/cm Items supplied Mounting bracket (1x) Mechanics/electronics Supply voltage 10 V … 30 V Ripple ≤ 10 % Voltage drop ≤ 1.5 V DC Current consumption 13 mA Time delay before availability ≤ 300 ms Temperature drift (of Sr) ± 20 % EMC EN 60947-5-2 Continuous current Ia ≤ 100 mA Cable material PVC Conductor size 0.14 mm² Short-circuit protection ✔ Reverse polarity protection ✔ Power-up pulse protection ✔ Shock and vibration resistance 30 g, 11 ms / 6 pos., 6 neg. per axis, 10 … 150 Hz, 1.0 mm / 15 g Ambient operating temperature –25 °C … +80 °C Ambient temperature, storage –40 °C … +85 °C Housing material Plastic, PBT Tightening torque, max. 0.2 Nm Protection class III UL File No. NRKH.E191603 Safety-related parameters MTTFD 1,972 years DCavg 0 % TM (mission time) 20 years Installation note Remark Associated graphic see “Installation” A ≥ 10 mm (at factory setting) B 16 mm F ≥ 25 mm (at factory setting) Classifications eCl@ss 5.0 27270102 eCl@ss 5.1.4 27270102 eCl@ss 6.0 27270102 eCl@ss 6.2 27270102 eCl@ss 7.0 27270102 eCl@ss 8.0 27270102 eCl@ss 8.1 27270102 eCl@ss 9.0 27270102 eCl@ss 10.0 27270102 eCl@ss 11.0 27270102 eCl@ss 12.0 27274201 ETIM 5.0 EC002715 ETIM 6.0 EC002715 ETIM 7.0 EC002715 ETIM 8.0 EC002715 UNSPSC 16.0901 39122230 İlgili ürünler CQ4-08ENOKU1 – 6051012SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ4-08ENSKU1 – 6051011SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ4-08EPSKU1 – 6051009SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ28-10NNP-KW1 – 6030133SICKKapasitif Sensörler ₺2.500,00 Ürüne Git
Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 16 mm x 34 mm x 8 mm Sensing range Sn 0.5 mm … 6 mm Installation type Flush Non-flush Switching frequency 10 Hz Connection type Cable, 4-wire, 2 m Switching output PNP Output function NC Electrical wiring DC 4-wire Adjustment Teach-in by wire (full or empty) Enclosure rating IP67, IP68, IP69K Special features Detection of water-based liquids up to a conductivity of 50 mS/cm Items supplied Mounting bracket (1x) Mechanics/electronics Supply voltage 10 V … 30 V Ripple ≤ 10 % Voltage drop ≤ 1.5 V DC Current consumption 13 mA Time delay before availability ≤ 300 ms Temperature drift (of Sr) ± 20 % EMC EN 60947-5-2 Continuous current Ia ≤ 100 mA Cable material PVC Conductor size 0.14 mm² Short-circuit protection ✔ Reverse polarity protection ✔ Power-up pulse protection ✔ Shock and vibration resistance 30 g, 11 ms / 6 pos., 6 neg. per axis, 10 … 150 Hz, 1.0 mm / 15 g Ambient operating temperature –25 °C … +80 °C Ambient temperature, storage –40 °C … +85 °C Housing material Plastic, PBT Tightening torque, max. 0.2 Nm Protection class III UL File No. NRKH.E191603 Safety-related parameters MTTFD 1,972 years DCavg 0 % TM (mission time) 20 years Installation note Remark Associated graphic see “Installation” A ≥ 10 mm (at factory setting) B 16 mm F ≥ 25 mm (at factory setting) Classifications eCl@ss 5.0 27270102 eCl@ss 5.1.4 27270102 eCl@ss 6.0 27270102 eCl@ss 6.2 27270102 eCl@ss 7.0 27270102 eCl@ss 8.0 27270102 eCl@ss 8.1 27270102 eCl@ss 9.0 27270102 eCl@ss 10.0 27270102 eCl@ss 11.0 27270102 eCl@ss 12.0 27274201 ETIM 5.0 EC002715 ETIM 6.0 EC002715 ETIM 7.0 EC002715 ETIM 8.0 EC002715 UNSPSC 16.0901 39122230
