Detection of water-based liquids with conductivity up to 50 mS/cm; container diameter: min. 8 mm; container thickness: 0.5 mm … 6 mm (plastic), 0.5 mm … 4 mm (glass)
Items supplied
Mounting bracket (1x)
Mechanics/electronics
Supply voltage
10 V … 30 V
Ripple
≤ 10 %
Voltage drop
≤ 1.5 V DC
Current consumption
13 mA
Time delay before availability
≤ 300 ms
Temperature drift (of Sr)
± 20 %
EMC
EN 60947-5-2
Continuous current Ia
≤ 100 mA
Cable material
PVC
Conductor size
0.14 mm²
Short-circuit protection
✔
Reverse polarity protection
✔
Power-up pulse protection
✔
Shock and vibration resistance
30 g, 11 ms / 6 pos., 6 neg. per axis, 10 … 150 Hz, 1.0 mm / 15 g
