Home Kapasitif Sensörler CQ4-08EPOKP1 – 6051001 🔍 CQ4-08EPOKP1 – 6051001 ✉ Teklif Al Teklif Al Stok kodu: 6051001 Kategoriler: Kapasitif Sensörler Marka: SICK Açıklama Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 16 mm x 39.5 mm x 12 mm Sensing range Sn 1 mm … 8 mm 1 mm … 6 mm Safe sensing range Sa 5.76 mm Installation type Non-flush Flush Switching frequency 100 Hz Connection type Cable with connector M8, 3-pin, 0.3 m Switching output PNP Output function NC Electrical wiring DC 3-wire Adjustment Potentiometer, 5 turns (Sensitivity) Enclosure rating IP67 Items supplied Screwdriver for potentiometer adjustment (1 x) Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple ≤ 10 % Voltage drop ≤ 2.5 V DC Current consumption 12 mA Time delay before availability ≤ 200 ms Hysteresis 4 % … 20 % Reproducibility ≤ 5 % Temperature drift (of Sr) ± 20 % EMC According to EN 60947-5-2 Continuous current Ia ≤ 150 mA Cable material PVC Short-circuit protection ✔ Reverse polarity protection ✔ Power-up pulse protection ✔ Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm Ambient operating temperature –20 °C … +75 °C Ambient temperature, storage –40 °C … +85 °C Housing material Plastic, ABS Sensing face material Plastic UL File No. NRKH.E191603 Safety-related parameters MTTFD 1,344 years DCavg 0 % TM (mission time) 20 years Reduction factors Note The values are reference values which may vary Metal 1 Water 1 PVC Approx. 0.4 Oil Approx. 0.25 Glass 0.6 Ceramics 0.5 Alcohol 0.7 Wood 0.2 … 0.7 Installation note Remark Associated graphic see “Installation” A 16 mm B 16 mm F 48 mm Classifications eCl@ss 5.0 27270102 eCl@ss 5.1.4 27270102 eCl@ss 6.0 27270102 eCl@ss 6.2 27270102 eCl@ss 7.0 27270102 eCl@ss 8.0 27270102 eCl@ss 8.1 27270102 eCl@ss 9.0 27270102 eCl@ss 10.0 27270102 eCl@ss 11.0 27270102 eCl@ss 12.0 27274201 ETIM 5.0 EC002715 ETIM 6.0 EC002715 ETIM 7.0 EC002715 ETIM 8.0 EC002715 UNSPSC 16.0901 39122230 İlgili ürünler CQ28-10NPP-KW1S02 – 6037194SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ4-08ENOKU1 – 6051012SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ4-08ENSKT1 – 6051006SICKKapasitif Sensörler ₺2.500,00 Ürüne Git CQ28-10NNP-KW1S03 – 6049010SICKKapasitif Sensörler ₺2.500,00 Ürüne Git
Tecnichal data Features Housing Rectangular Dimensions (W x H x D) 16 mm x 39.5 mm x 12 mm Sensing range Sn 1 mm … 8 mm 1 mm … 6 mm Safe sensing range Sa 5.76 mm Installation type Non-flush Flush Switching frequency 100 Hz Connection type Cable with connector M8, 3-pin, 0.3 m Switching output PNP Output function NC Electrical wiring DC 3-wire Adjustment Potentiometer, 5 turns (Sensitivity) Enclosure rating IP67 Items supplied Screwdriver for potentiometer adjustment (1 x) Mechanics/electronics Supply voltage 10 V DC … 30 V DC Ripple ≤ 10 % Voltage drop ≤ 2.5 V DC Current consumption 12 mA Time delay before availability ≤ 200 ms Hysteresis 4 % … 20 % Reproducibility ≤ 5 % Temperature drift (of Sr) ± 20 % EMC According to EN 60947-5-2 Continuous current Ia ≤ 150 mA Cable material PVC Short-circuit protection ✔ Reverse polarity protection ✔ Power-up pulse protection ✔ Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm Ambient operating temperature –20 °C … +75 °C Ambient temperature, storage –40 °C … +85 °C Housing material Plastic, ABS Sensing face material Plastic UL File No. NRKH.E191603 Safety-related parameters MTTFD 1,344 years DCavg 0 % TM (mission time) 20 years Reduction factors Note The values are reference values which may vary Metal 1 Water 1 PVC Approx. 0.4 Oil Approx. 0.25 Glass 0.6 Ceramics 0.5 Alcohol 0.7 Wood 0.2 … 0.7 Installation note Remark Associated graphic see “Installation” A 16 mm B 16 mm F 48 mm Classifications eCl@ss 5.0 27270102 eCl@ss 5.1.4 27270102 eCl@ss 6.0 27270102 eCl@ss 6.2 27270102 eCl@ss 7.0 27270102 eCl@ss 8.0 27270102 eCl@ss 8.1 27270102 eCl@ss 9.0 27270102 eCl@ss 10.0 27270102 eCl@ss 11.0 27270102 eCl@ss 12.0 27274201 ETIM 5.0 EC002715 ETIM 6.0 EC002715 ETIM 7.0 EC002715 ETIM 8.0 EC002715 UNSPSC 16.0901 39122230
