Technical Specs
Specifications
Product Type:I/O Modules
Sub Brand:ControlLogix
Type:Counter Module
Special Features:1MHz Counter Interface, 250KHz Encoder Interface (x1 and x4), Two Outputs assignable to each Counter, 3 different frequency calculations
Mounting:Chassis
Enclosure:None (open-style)
Input Signal:TTL Inputs: 4.5 – 5.5vdc, 24vdc Inputs: 10 – 26.4vdc
Output Signal:4.5-5.5VDC, 10-31.2VDC
Isolation:30 V continuous between input groups
Display:Input, Output, Communication, and Operational Status, Module Health
Operating Temperature:0…60 °C (32…140 °F)
Removable Terminal Block:1756-TBCH or 1756-TBS6H
I/O Modules
Specialty Modules (Please select number of Removable terminal Blocks as addded in the list.):2 Channel / 4 Output High Speed Counter (36 Pin)
