| certificates / approvals |  |
 |
rated insulation voltage Ui |
600 V |
|---|---|
surface finish |
AgNi |
utility category |
3 A (AC-15 at 250V AC) / 10 A (DC-13 at 24V DC) |
max. conductor cross section |
2.5 mm² |
connection type conductor |
screw connection |
number of contacts as normally closed contact |
2 |
number of contacts as normally open contact |
1 |
min. switching voltage |
5 V |
min. ambient temperature |
-30 °C |
max. ambient temperature |
70 °C |
switching principle contact elements |
slow action switch |
min. switching current |
1 mA |
B10d-value |
250000 |
illumination connection |
no |
fall-off protection |
yes |
build in depth |
62 mm |
|---|
ECLASS 11 |
|
|---|---|
ECLASS 8.1 |
27371302 |
ETIM 9.0 |
EC000041 |
ETIM 8.0 |
EC000041 |
ETIM 7.0 |
EC000041 |
ETIM 6.0 |
EC000041 |
ETIM 5.0 |
EC000041 |
ETIM 4.0 |
EC000041 |
ROHS conformity status |
compliant |
|---|---|
REACH-SVHC conformity status |
compliant |
