Technical Specs
Specifications
Voltage Rating:400 VAC, 3 PH
Lifecycle Status Note
LifeCycle Status Note:PowerFlex 700 Frame 7-10 Drives are now Discontinued. We recommend that you consider the new generation PowerFlex 755 drive family as an alternative.
Base Drive Information
Input Voltage:400 VAC, 3 PH
Output Current:140 Amps
Enclosure:IP20 / Type 1, with conformal coating
Frame Size:Frame Size 5
I/O:Vector Control with 24V I/O
Brake IGBT:Brake IGBT Installed
Brake Resistor:No Brake Resistor
EMC Filtering Options:Second Environment Filter per CE EMC directive (89/336/EEC)
Options Information
Base Plus Options:Base Plus Options Method
Internal Communication Module:No Communication Module
Voltage Rating:400 VAC, 3 PH
Lifecycle Status Note
LifeCycle Status Note:PowerFlex 700 Frame 7-10 Drives are now Discontinued. We recommend that you consider the new generation PowerFlex 755 drive family as an alternative.
Base Drive Information
Input Voltage:400 VAC, 3 PH
Output Current:140 Amps
Enclosure:IP20 / Type 1, with conformal coating
Frame Size:Frame Size 5
I/O:Vector Control with 24V I/O
Brake IGBT:Brake IGBT Installed
Brake Resistor:No Brake Resistor
EMC Filtering Options:Second Environment Filter per CE EMC directive (89/336/EEC)
Options Information
Base Plus Options:Base Plus Options Method
Internal Communication Module:No Communication Module
