Tecnichal data
| Suitable for illumination | No |
| Operator cap/button shape | Round |
| Illumination lamp type | No power module |
| Contact block type | Standard |
| Illumination module type | No power module |
| Operator cap/button material | Plastic |
| Contact block thermal current rating | 10 A |
| Illumination module input voltage | No power module |
| Contact block utilization category (AC) | A600, AC 15 – screw termination |
| Contact block utilization category (DC) | Q600, DC-13 – screw termination |
| Contact block operational voltage, max | 600V (A600, Q600) – screw termination |
| Operator cap type | Flush alternate action |
| Hole diameter | 22.5 mm |
| Latch material | Metal |
| Operator mechanical design life (cycles, min.) | 1.0E7 |
| Contact block durability | 1.0E7 |
| Contact block mounting style | Latch |
| Operator cap text/symbol | Optional |
| Illumination module termination wire range | #18…12 AWG (0.75…2.5 mm^2) |
| Operator function | 22 mm momentary push button |
| Contact block termination tightening torque | 6 – 8 lb – in / 0.7 – 0.9 N-m |
| Operator type | Push button |
| Enclosure compatibility | IP66, Type 4/13 (Round metal operator) |
| Contact block configuration | 2 NC |
| Shock | 100 G |
| Vibration | 10 G |
| Contact block termination wire range | #18…12 AWG (0.75…2.5 mm^2) |
| Illumination module termination tightening torque | 6 – 8 lb – in / 0.7 – 0.9 N-m |
| Operating temperature | -25 ðC |
| Humidity | ââ°¤95% RH from 25…60 ðC (77…140 ðF) |
| Storage temperature | -40 ðC |
| Illumination module mounting style | Latch |
| Operator construction/material | Metal |
| Termination style | Screw contact block |
| Operator cap color (lens) | Black |
| Certifications | UL,UR, CSA, CCC, CE |
