Tecnichal data
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as normally closed contact | 1 |
| Number of poles | 3 |
| Conditioned rated short-circuit current Iq | 20 kA |
| Rated permanent current Iu | 25 A |
| Rated operation power at AC-23, 400 V | 11 kW |
| Max. rated operation voltage Ue AC | 600 V |
| Rated operation power at AC-3, 400 V | 7.5 kW |
| Rated short-time withstand current lcw | 900 kA |
| Type of control element | Door coupling rotary drive |
| Rated frequency | 60 Hz |
| Switch size | 25 A |
| Lost power per pole | 1 W |
| Conventional free air thermal current (Ith) | 40 A per IEC |
| Conventional enclosed thermal current (Ie) | 32 A per IEC |
| Rated operational voltage (Ue) | 690V per IEC |
| Rated isolation voltage (Ui) | 690V per IEC |
| Continuous current | UL/CSA (applications): 25 A |
| Rated breaking capacity | AC-23A (cosÃâ0.45): 296 A @ 230V |
| Motor FLA rating | UL/CSA application: 8.5 A @ 480V, 60 Hz, 1 pole, 1 phase |
| Hp motor rating | UL/CSA application: 5 Hp @ 600V, 60 Hz, 1 pole, 1 phase |
| Fuse rating of circuit (type g, G), max | Short circuit current (co-ordination type 2): 25 A @ 400/415V |
| Rated current (Ie) | DC-21A (for resistive loads): 5 A @ 220V, 2 pole in series, T ââ°¤1 ms, Ue max = 660V |
| Rated power (Pe) | AC-3: 7.5 kW @ 690V |
| Number of switches | 1 |
| Motor drive integrated | No |
| Motor drive optional | No |
| Voltage release optional | No |
| Type of electrical connection of main circuit | Screw connection |
| Switching rate | 120 ops/h |
| Rated impulse voltage (Uimp) | 8 kV per UL, CSA |
| Test voltage (Ui) | 2.5 kV for 1 minute |
| Heavy pilot duty | UL/CSA (applications): A600, AC |
| Interlockable | No |
| Version as emergency stop installation | Yes |
| Degree of protection (NEMA) | 1 |
| Degree of protection (IP) | IP54 |
| Material housing | Steel |
| Tightening torque | 2 Nm (17 lb-in) |
| Enclosure size | Standard size enclosure |
| Rigid wire gauge | 1.5…16 mm2 (14…8 AWG) |
| Fine strands wire gauge | 1.5…10 mm2 (14…8 AWG) |
| Wire gauge, max | Terminal size per IEC 947-1: A6 |
| Left side mounting | Auxiliary contact (1 NO, 1 NC) |
| Right side mounting | No modification |
| Protection class according to IEC 529 | Switch bodies: IP20 @ motor rating 60 Hz |
| Version as safety switch | No |
| Version as reversing switch | No |
| Version as main switch | Yes |
| Version as maintenance-/service switch | Yes |
| With transparent cover | No |
| Mechanical life operations | 200000 |
| Model | Surface mounting |
| Suitable for front mounting 4-hole | No |
| Suitable for front mounting centre | No |
| Colour control element | Black |
| Device construction | Complete device in housing |
| Actuator colour | Grey/black |
| Enclosed switch height, approx | Oversized enclosure: 167.38 mm (6.59 inch) @ 63 A |
| Enclosed switch depth, approx | Oversized enclosure: 210.57 mm (8.29 inch) @ 63 A |
| Enclosed switch width, approx | Oversized enclosure: 241.3 mm (9.50 inch) @ 63 A |
| Installation | NEMA 1-IP54 painted steel-base/DIN rail |
| Suitable for floor mounting | No |
| Suitable for distribution board installation | No |
| Suitable for intermediate mounting | No |
| Ambient enclosed temperature | -20 ðC |
| Ambient storage temperature | -40 ðC |
| Ambient operation temperature | -25 ðC |
