Technical Specs
Specifications
I/O Platform:Bulletin 1756 I/O Modules, Bulletin 1764 MicroLogix 1500 I/O, Bulletin 1769 I/O Modules, Bulletin 1794 I/O Modules, Bulletin 700H/700S Drive I/O Modules
Type:Digital Module with Field Removable Terminal Block
Connection:20 Pins
Special Features:Standard
I/O Module Data
Please Note:You must select an I/O Module in order to choose a Pre-Wired Cable with Connectors on Both Ends
Wiring Systems Data
Product Type:Digital Module with Field Removable Terminal Block
Cable Connector Pin Type:20 Pins
Interface Module Style:Feed-Through
Terminal Features:Standard
LED or Fuse Voltage:None
Field Side Terminals:One per I/O Connection
Rtb Plug Assembly Data
Please Note:An RTB plug assembly is required with this Removable Terminal Block module. The module itself is supplied without any RTB plug assemblies. You should select the RTB plug assembly to complete this configuration.
