Technical Specs
Specifications
Connection:Screw Terminals
3-Phase kW (50 Hz) 400V/415V Rating:5.5
3-Phase kW (50 Hz) 500V Rating:5.5
3-Phase kW (50 Hz) 690V Rating:5.5
1-Phase HP (60 Hz) 115V Rating:0.5
3-Phase HP (60 Hz) 460V Rating:7.5
3-Phase HP (60 Hz) 575V Rating:10
Contactor Data
Terminal Type:Screw Terminals
Rated Operating Current, AC-3:12A
Coil Voltage:110V 50/60Hz
Coil Termination:Line Side
Contact Configuration:0 N.O. 1 N.C. Auxiliary Contact Configuration
Package Quantity:1
Application Data
Electrical Standards:UL
Load Data [Optional]
Utilization Category:AC-3 Squirrel-cage motor starting and stopping
Life Data [Optional]
Actual Life:Actual Life Cannot be Calculated (more information)…
Terminal Marking Positions Used
100-C or 104-C Contactor:2_
Front Mounted Auxiliary Contact:None
Left Side Auxiliary Contact:None
Right Side Auxiliary Contact:None
Interlock:None
Connection:Screw Terminals
3-Phase kW (50 Hz) 400V/415V Rating:5.5
3-Phase kW (50 Hz) 500V Rating:5.5
3-Phase kW (50 Hz) 690V Rating:5.5
1-Phase HP (60 Hz) 115V Rating:0.5
3-Phase HP (60 Hz) 460V Rating:7.5
3-Phase HP (60 Hz) 575V Rating:10
Contactor Data
Terminal Type:Screw Terminals
Rated Operating Current, AC-3:12A
Coil Voltage:110V 50/60Hz
Coil Termination:Line Side
Contact Configuration:0 N.O. 1 N.C. Auxiliary Contact Configuration
Package Quantity:1
Application Data
Electrical Standards:UL
Load Data [Optional]
Utilization Category:AC-3 Squirrel-cage motor starting and stopping
Life Data [Optional]
Actual Life:Actual Life Cannot be Calculated (more information)…
Terminal Marking Positions Used
100-C or 104-C Contactor:2_
Front Mounted Auxiliary Contact:None
Left Side Auxiliary Contact:None
Right Side Auxiliary Contact:None
Interlock:None
